Electrical Straight Coupler
38
2.64 in
67.0 mm
DataTrack/DataTrack Backbone System Planning and Installation Manual
• Used for splicing two pieces of
DataTrack in line
• Requires 4 in (10.16 cm) pendant clip
to stabilize joint (see
Pendant Clip on page 42
DataTrack
Color Model Number
Black EDTRSC
White EDTRSC-1
Silver EDTRSC-5
Related Accessories: DataTrack
Backbone Straight Locking Joint
Color Model Number
N/A DTB-LJ
1.42 in
36.1 mm
Four-inch
)
0.42 in
10.6 mm
