Nav Strip

NOTE: The examples shown are from
the TouchMix-30 Pro. TouchMix-8 and
TouchMix-16 will differ slightly.
The Nav Strip provides the primary means of navigating
between fader banks. In addition, it provides an overview
of all fader positions for the selected mix and any clipping
conditions.
To access the Nav Strip
Blue Nav Strip Bank
– Indicates the type and range of the channels.
Nav Strip Titles
– The faders represent the current position of all the mixer's faders for the currently selected mix (Main, Auxes 1 - 14).Fader levels are
Faders
not adjustable from the Nav Strip
– This is a "sticky" clipping indication the channel is, or has been clipping. Reduce the input channel trim, then go to Menu
Red Fader Slot
> Mixer Setup > Clear Clip, or push the Clear Clip user button.
Inputs 1–8, 9–16, and 17–24
– Displays the fader settings for line inputs and for 2-track playback and record.
Stereo In/2-Track
FX Masters – Displays the level of the returns for the internal effects processors.
Aux Outputs 1–8, 9–14
– Displays the level of the eight Sub Groups (TouchMix-30 Pro only).
Sub Groups 1–8
– Displays the level of the eight DCA master faders. Refer to the
DCA Groups
1001108-01-F
– From any screen, press Home once or twice to display Home page.
– Indicates the currently selected bank. Touch the bank to select it.
– Displays the fader settings for mic/line inputs.
– Displays the level of the auxiliary outputs.
Inputs 1-8 Inputs 9-16 Inputs 17-24 Stereo In/2-Trk
DCA Group Assignments on page 108
39
Home
FX Masters Aux Out 1-8 Aux Out 9-14 Sub Groups
Home
(if needed)
DCA Groups
