Patch Matrix (TouchMix-30 Pro only)

Manages connections between physical inputs and on-
screen channels.
1. – Displays the name of the current
Preset
preset. "Default routing" is the Reset or factory
default Preset.
2. button – Navigates to the
Save / Recall
Patch Matrix Preset screen where patch matrix
settings may be stored or recalled. Use Home to
return to the Patch Matrix screen.
3. button – Restores the default settings.
Reset
4. select buttons – Used to select a
Input
physical input for rerouting.
5. / – Moves between Input groups 1–16
and 17–30.
6. Channel select buttons – Selects the Channel
to be connected to the selected Input.
7.
Channels 17-30
1–16 – Moves between channel groups
1–16 and 17–30.

Using the Patch Matrix

NOTE: The Patch Matrix should be
used with care. It is easy to set up
confusing routings that make
troubleshooting difficult.
The image illustrates a "mult" (short for multiple connection). Perhaps the mixer operator needs to apply different channel processing to the
Acoustic Guitar for Mains and Monitors.
1. Open the Patch Matrix.
2. Select the input the Acoustic Guitar is connected to (Input 10).
3. Mult the input to the second channel by touching 11 Ac Guitar. Input 10 is now feeding both channels.
4. Any input can be routed to any channel or any combination of channels.
5. When an input is re-patched, the channel name changes to include the name of the physical input. In the above example, channel 11
would become "[In 10] Ac Guitar".
1001108-01-F
Menu
Main Mix
L/R
Joe's Monitor
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
and Channels
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
Patch
Matrix
Patch Matrix
1
To configure routing, select an Analog Input from the top row,
Preset Default Routing
then select Destination Channels from the right column.
4
Input Input Input Input Input Input Input Input Input Input
1 2 3 4 5 6 7 8 9
120
Press Menu
2 3
Save / Recall
5
Input Input Input Input Input Input
Patch Matrix
10 11 12 13 14 15 16
Kick
1
Snare
2
3 Hat
4 Tom
5 Tom
6 Tom
7 CH
8 CH
9 E Bass
10
Ac Guitar
11 Ac Guitar
12 Sax
13 Trombone
14 Kazoo
15 Cajone hole
16 Cajone Slap
7
Channels 17-30
Touch Patch
Matrix
Scene:
Default
Reset
Main
Cue
Main
L/R
10 10
6
5
L
u
F
5
10
20
0
40
∞
Mute
