Record / Playback (Multitrack USB Drive)

Provides the controls to record and playback
multiple channels.
Record / Playback – Main Screen
IMPORTANT!: All USB memory
devices must be formatted as FAT32.
Drive performance is critical for
recording. For more information and to
see a list of qualified drives, visit qsc.
com.
NOTE: At the end of a session, the
recording must be stopped using the Stop/
Pause control. Stopping the recording
writes a header file that is required for the
tracks to play.
NOTE: All the standard channel
controls act as they do regardless of
record / playback status. For example, if
you Mute the channel that is recording, the
output gets muted, but recording of the
input continues.
1.
Input Channel controls
2. – Arms the channel to be recorded when the Record button is pressed. Displays here and on the Home screen .
Arm
3. – When engaged, selects a recorded track as the audio source for the channel instead of the analog input.
Track
4. – Displays the name of the active multi-track recording session.
USB Session
5. Transport controls
6.
Total record time counter
until the recording is ended.
7. Recording Mode – Displays a panel for selection of Stereo MP3, Multitrack or DAW (see the MP3 Audio Player and DAW topics).
8. – Moves the Locate pointer to the position of the Play pointer.
Set
9. – Moves the Play pointer to the position of the Locate pointer.
Go To
10. – Indicates current record/playback position.
Play pointer
11. Locate pointer – Marks a location on the Time Line. The locate pointer may be moved by dragging on screen, by selecting and
turning the Master Encoder or using the Set button.
12.
Progress indicator
NOTE: Due to FAT23 file size limitations, the max continuous recording time is roughly three hours. A warning message is
displayed 10 minutes before the limit is reached. To continue recording, pause and then resume. It is not necessary to create a new
session. (see "Recording Directory Structure" for more).
13.
Time code display
the attached hard-disc drive.
14.
Recording Setup
1001108-01-F
– All input channel controls function as they do from the Home screen.
– Standard transport controls; Return to Start, Rewind, Play, Forward, Pause and Record.
– The total length of the recording in HH:MM:SS. If recording is in progress, this number grows
– Represents the session time line.
– Displays position of the Play pointer in HH:MM:SS. Maximum record time is determined by the capacity of
– Navigates to the Recording Setup screen.
Recording
Multitrack
Rec/
Play
Mode USB Drive
99
Touch
Press
Recording
Rec/Play
Mode
Touch
Multitrack
USB Drive
