Input Channel − Compressor
The Compressor controls the dynamic range of a signal
above a set Threshold.
1. – Selects the Compressor screen.
Comp tab
2. Comp In / Out switch
disengages the compressor.
3.
Knee In button
Determines
–
how abruptly
the compressor
transitions in and
out of gain reduction
as the threshold
is crossed.
4. Turns Simple mode on
Simple button –
and off. Hides all controls except:
• Comp In
• Simple
• Reset
• Compression
5. Sets all the Comp controls
Reset button –
to their factory default position.
6. RMS input level
In meter –
7. Gain Reduction – (red)
G.R. meter –
indicates how much the signal is being reduced
by the compressor.
8. Output level after any applied compression
Out meter –
9.
Threshold slider –
10. Compressor graph
trace is displayed.
• (A) – The level at which compression begins.
Threshold
• (B to E) – The time it takes for the compression to reach its maximum compression after the input exceeds the threshold level.
Attack time
• (A to E) – The amount of compression applied to the signal.
Ratio
• (C to D) – The time it takes for the compressed signal to rise to the threshold level once the input level no longer exceeds the threshold.
Release time
11. – Sets the ratio of input level to output level when the signal exceeds the threshold.
Ratio slider
12. – Adjusts how quickly the compressor reacts to a signal that exceeds the threshold.
Attack slider
13. Release slider – Adjusts how quickly the compressor stops compressing when signal falls below threshold.
14. – (Compressor only) Adjusts the overall output gain to makeup any loss after the signal is compressed.
Gain knob
15. Compressor indicator – When the Compressor is In, an orange "C" displays on the channel controls strip.
16. – Adjusts the amount of compression at the frequencies of sibilant consonants such as "s", "z", and "sh".
De-Esser knob
17. De-Esser button –
18.
Side Chain selector
channel. Touch the Side Chain selector box then use the Master Encoder to adjust.
19. Side Chain In – (TouchMix-30 Pro only) Engages or disengages the side chain. When the side chain is disengaged, the input of the
currently selected channel controls its own compression.
1001108-01-F
– Engages and
Main Mix
L/R
Joe's Ears
Aux 1
Aux 2
Aux 2
Knee
Aux 3
Aux 3
In Out
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
Sets the point at which the compressor will begin to reduce signal level.
– Vertical scale from 0 dB to -60 dB; horizontal measurement is time. When the Compressor is engaged, the
Engages or disengages the De-Esser.
– (TouchMix-30 Pro only) Selects another input channel to control the compression of the currently selected
