FX Masters

FX Master − Overview
Provides a single-screen view of frequently used
controls and indicators for the FX channel.
1. Overview tab – Selects the Channel
Overview screen.
2. Preset – Shows the currently selected Preset
for this channel. Touch the + to change.
3. – Shows the currently selected Effect
Effect
type for this channel. Touch the + to change.
4.
Pre Fader / Post Fader button
– Selects the Aux mix pick-off point for the
effect. Selections are: Pre Fader – before the FX
master fader, or Post Fader – after the FX master
fader.
5. – Sets all controls for the FX
Reset button
channel to the factory default position.
6. – Indicates the output
Assigned To
assignments channel (L/R Main, Sub Groups
1 - 8).
7. – Indicates the DCA groups to which this
DCA
channel is assigned.
8. – Indicates the Mute groups to which
Mute
this channel is assigned.
9.
Parametric EQ graph
representation of the equalization curve based
on the EQ settings. The trace dims to indicate
that the EQ is Out (disengaged).
•
EQ Graph vertical scale
•
EQ Graph horizontal scale
10. Out/In – Engages / disengages the equalizer for the FX channel.
EQ
11. –
Aux Sends
• Displays the system numbers and user-defined names for the Aux channels.
• Adjustable sliders send signal to the associated Aux channel output.
• Mute indicates if the channel's send to an Aux is muted or not.
12. Touch, hold, and drag to change the Frequency and Gain of the associated EQ band. The frequency band button
EQ Handles –
must be engaged to see the EQ Handles.
13. and
Low Cut Filter
NOTE: To adjust the following parameters, select the field then use the Master encoder or the up/down nudge buttons on a
mobile device.
14.
Gain, shelf filters 1 and 2
15.
Low-Cut filter frequency
16.
Shelf filters 1and 2 frequency adjustment fields
bands.
17.
Aux number & name
18. – Indicates if the FX channel send to the Aux mix is muted. You can change this in the FX Masters Auxes tab.
M
1001108-01-F
Main Mix
L/R
Joe's Monitor
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
– A graphic
Aux 14
Aux 14
– Represents audio level from -20 dB to +20 dB.
– Represents frequency from 20 Hz to 20 kHz.
– These buttons engage or disengage the associated filter.
Shelf filters 1 and 2
– Displays and adjusts gain (+/- 15 dB) of the frequency band.
– Displays and adjusts the knee frequency for the high and low cut filters.
– Displays the system numbers and user-defined names for the Aux mixes.
