MIDI

The MIDI (Musical Instrument Digital Interface) Setup
provides the means to use a "class compliant" USB MIDI
foot switch to control many functions of the TouchMix
mixer. This screen is not available on remote devices.
QSC has verified proper operation with these USB MIDI
foot-switches: iCON G-BOARD and Logidy UMI3
NOTE: Only On/Off commands are
supported. The mixer does not respond to
continuous controller data.
1.
MIDI Functions –
assignments are displayed on MIDI buttons 1 – 8.
Blue indicates the MIDI function is selected and
can be assigned/unassigned or renamed.
2. Displays the name of the currently
Name –
assigned MIDI function. A name is automatically
assigned when a function is selected in the
Action, Selection, Detail fields.
3. After making your
Assign button –
selection, touch this button to assign your
selection to the selected MIDI.
4. Unassign – Touch this button to remove the
assignment to the selected MIDI button.
5. This list is a general list of types of
Action –
things the MIDI controller can affect. For example "Recall Scene".
6. When an Action is chosen, a list of ways the action can be applied are displayed. For example "Factory".
Selection –
7. Displays a list of specific targets for the selection. For example "Drum Sub Mix".
Detail –
8.
MIDI Assignment –
9. Learn MIDI –
a. Touch this button to teach the TouchMix what MIDI command should trigger the selected action.
b. A message displays saying, "Waiting for incoming MIDI message..."
c. Press a button on the USB MIDI device.
d. When the USB MIDI device button is pressed, the TouchMix responds by executing the assigned function.
