Sub Groups (TouchMix-30 Pro only)

Sub Group − Overview
Provides a single-screen view of frequently used
controls and indicators for the Sub Groups.
1. – Selects the Sub Group
Overview tab
Overview screen.
2. – Shows the currently selected Preset
Preset
for this sub group. Cannot be changed from this
screen.
3. – Sets all controls for the sub group to
Reset
the factory default position.
4. – Indicates whether or not the sub
L/R Subs
group is assigned to the Main output.
5.
Parametric EQ Graph
representation of the equalization curve based
on the EQ settings. The trace dims to indicate
that the EQ is Out (disengaged).
•
EQ Graph Vertical Scale
Represents audio level from -20 dB to +20 dB.
•
EQ Graph Horizontal Scale
Represents frequency from 20 Hz to 20 kHz.
6. – Engages / disengages the equalizer
EQ In
for the sub group.
7. –
Aux Sends
• Displays the system numbers and user-defined
names for the Aux channels.
• Adjustable sliders send signal to the associated
Aux channel output.
• Mute indicates if the channel's send to an Aux is muted or not.
8. Touch, hold, and drag to change the Frequency and Gain of the associated EQ band. The frequency band button
EQ Handles –
must be engaged to see the EQ Handles.
9.
Low and High Cut Filter
associated filter.
To adjust the following parameters, select the field then use the Master encoder or the up/down nudge buttons on a mobile device.
10. – Displays and adjusts gain (+/- 15 dB) of the frequency band.
Gain, Bands 1–6
11. Low and High Cut Filter Frequency
12.
Frequency Bands 1–6 frequency adjustment fields
parametric EQ bands.
13.
Comp –
• – Engages or disengages the channel's dynamics processor.
Comp
• – Displays and sets the level at which compression/limiting begins.
Threshold
• – Displays and sets the time it takes for the compressor/limiter to reach its maximum compression when the threshold level is
Attack
exceeded.
• – Displays and sets the time it takes for the compressor/limiter to cease gain reduction when signal drops below threshold.
Release
• – Displays and sets the amount of compression applied to the signal.
Ratio
• – Displays and sets the overall output gain to makeup any loss after the signal is compressed.
Gain
• – Gain reduction meter shows the amount of compression applied to the signal.
G.R.
14. –
FX Sends
• Displays the system numbers and user-defined names for the FX channels.
• Adjustable sliders send signal from this channel to the associated FX processors.
15.
Aux Number & Name
1001108-01-F
Main Mix
L/R
Joe's Ears
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
– A graphic
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
9
Aux 7
–
Aux 8
11
Aux 8
Aux 9
Aux 9
–
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
and
Frequency Bands 1, 2, 3, 4, 5, 6
– Displays and adjusts the knee frequency for the high and low cut filters.
– Displays the system numbers and user-defined names for the Aux mixes.
Press Touch Sub
Home Group Bank
Sub Groups
Sub 1 Overview
Inputs 1-8
1
Overview EQ Comp
2
Preset Ele Gtr Dyn Rock 1
4
L/R Subs L/R
EQ
5
20
10
1 1 5 5
8
2
2
0 3 3
4 4
-10
-20
20Hz 50 100 200 500 1K 2K 5K
1 2 3 4 5 6
10
0.00 0.00 0.00 0.00 0.00 0.00
120 80.0 200 500 1.0k 3.0k 8.0k
12
Comp FX Sends 14
13
Threshold Mono Delay
1
G.R.
-12.0
2 Lush Reverb
Attack
16.0
3 Dense Reverb
Release
50.0
4 Pitch Shift
Ratio
4.0
5 Mono Delay
Gain
0.00
6 Lush Reverb
– These buttons engage or disengage the
– Displays and adjusts the center frequency for the four
