TouchMix-30 Pro Phones and Monitor

Phones and Monitor Level Control and Monitor settings.
NOTE: By default, no audio signal is
sent to the Phones / Monitor Outputs. To send audio channel signals
(including Main L/R) to the Phones / Monitor Outputs. Enable the Cue
button for the channels you want to listen to.

Phones Level

1.
Phones / Cue Level –
outputs.

Monitor Level and Settings

1. (Monitor) – Select the source you want to send to the Monitor output.
Source
2. – Engages / bypasses the delay.
In
3. Delay – The delay is used to align the audio coming from a distant stage with
the near-field monitor signal heard at the mixer position. Digital readouts are in
feet, milliseconds, and meters.
4. Adjust the output level for the Monitor.
TouchMix-8 and TouchMix-16 Phones
and TouchMix-16 Monitor
Controls the output level for the Phones Cue and Monitor Cue
NOTE: The Monitor Level control is available only on the TouchMix-16.
Phones (1) and Monitor (2) Level
Phones and Monitor outputs.
NOTE: By default, no audio signal is sent to the Phones / Monitor Outputs. To
send audio channel signals (including Main LR) to the Phones / Monitor Outputs.
Enable the Cue button for the channels you want to listen to.
1001108-01-F
Controls the level of the signal on the Phones
– Controls the level of the Cue signal on the
Phones
Phones
Close
Phones
1
2
116
Press Phones OR Press Monitor Press Phones OR Press Monitor
Monitor
Monitor
1
1
Source
10
Aux 1 Aux 2 Aux 3
5
Aux 5 Aux 6 Aux 7
U
-5
Aux 9 Aux 10 Aux 11
-10
Aux 13 Aux 14 Main LR
-20
Delay
2
-40
In
3
Close
Press Phones OR Press Monitor
Monitor
10
Aux 4
5
Aux 8
U
-5
Aux 12
-10
Cue
-20
-40
0.00 ms
0.00 feet
0.00 m
4
