Input Channel − EQ
Controls and displays the settings for the Input Channel
equalization.
1. – Selects the EQ screen.
EQ tab
2. EQ In – Engages / disengages the equalizer.
3. – Engages the Real Time Analyzer
RTA On
display.
NOTE: A maximum of two RTA
displays for TouchMix-30 Pro, and one RTA
display for the TouchMix-8 and -16 are
available at a time on any combination of a
mixer and tablet devices.
NOTE: When the RTA is off, the
Parametric EQ graph expands to use the
entire graph area.
4. – Hides the Low Cut, High
Simple button
Cut, Frequency, and BW controls. Does not effect
existing settings.
5. – Sets all the EQ controls to
Reset button
their factory default position.
6. – Displays the amplitude of the
RTA display
channel signal in 1/3 octave bands. Peak hold is
displayed only on tablet devices.
7.
Parametric EQ graph
that the EQ is Out (disengaged).
•
EQ graph vertical scale
•
EQ Graph horizontal scale
8. EQ Handles – Touch, hold, and drag to change the Frequency and Gain of the associated EQ band. The frequency band button
must be engaged to see the EQ Handles.
9.
Low Cut and High Cut filter buttons
corresponding Freq control.
10.
Low Shelf and High Shelf filter buttons
When a shelf filter is engaged, the Bandwidth control is not available.
11. Frequency Bands 1, 2, 3, and 4 buttons
parametric with a frequency range of 20 Hz to 20 kHz.
12.
Gain control knob and readout
+15 dB.
13.
Freq control knob
engaged, the Freq control sets the knee frequency of the shelf filter.
14. Q knob – Adjusts the bandwidth of the associated EQ band. When the Shelf Filter is selected, the Bandwidth control is hidden. In
addition, Q can be adjusted by "pinching" (TouchMix-30 Pro and tablet apps only).
15.
Freq control knob
below 0 or unity.
16. – Navigates to the next or previous channel. The buttons cycle through the Input, playback, record, and FX channels,
buttons
then loops back to Input 1.
17. Channel controls
18.
Main Channel controls –
1001108-01-F
Main Mix
L/R
Joe's Ears
Aux 1
Aux 2
Aux 2
Aux 3
Aux 3
Aux 4
Aux 4
Aux 5
Aux 5
Aux 6
Aux 6
Aux 7
Aux 7
Aux 8
Aux 8
Aux 9
Aux 9
Aux 10
Aux 10
Aux 11
Aux 11
Aux 12
Aux 12
Aux 13
Aux 13
Aux 14
Aux 14
– A graphic representation of the equalization curve based on the EQ settings. The trace dims to indicate
– Represents audio level from -20 dB to +20 dB.
– Represents frequency from 20 Hz to 20 kHz.
– These filters cut frequencies below or above the frequency set by the
– Adjusts the gain at the frequency setting of the associated EQ band. Range of -15 dB to
(Frequency bands 1 – 4) – Sets the center frequency of the associated EQ band. If the Shelving filter is
(Low and High Cut) – Sets the frequency of the low and/or high cut filter as measured from a point 3 dB
– Output controls for selected channel. See Channel Controls topic.
Output controls for the Main L/R outputs. See Channel Controls topic.
