FX Overview

Provides an overview of the channel FX Send and
Return levels.
FX sends and FX Master levels may be adjusted by
touching (selecting) the control then using the Master
Encoder or the Nudge buttons on a tablet device.
FX Overview Screen
NOTE: Only Input
banks are selectable on the
Group
Nav Strip.
1. Select an Input or Sub Group bank.
2. Each column (In 1, In 2 ...) represents a channel,
and lists the channel's six FX Sends.
3. Each row represents an FX mix, and lists the FX
Sends for the mix.
4. FX Master fader – Adjusts the overall
level of the effect that will be heard in the mix.
5.
FX Processor Icon
currently selected FX device for the FX mix.
1001108-01-F
Menu
and Sub
– Indicates the
FX
Overview
1
2
3
80
Touch FX
Press Menu
Overview
4
5
