Sub Group − Setup
(TouchMix-30 Pro only)
Rename the Sub Channel, assign Input channels to the
group, and assign/unassign the group to the Main L/R.
1. – Selects the Sub Group Setup
Setup tab
screen.
2. – Touch the Name to display a
Name
keyboard that may be used to enter a name for
the channel.
3. Touch the Link button to link the
Link –
channel with the adjacent channel. Always links
odd to even.
4. Returns settings to the factory
Reset –
default.
5. Select "Yes" to automatically
No/Yes –
unassign an input channel from the Main L/R
when it is assigned to the Sub Group.
6. Input Channel numbering, both system (1) and
user assigned (In 1).
7. L/R
L/R assigned
Group is assigned to the Main L/R outputs.
L/R
8.
L/R unassigned
Sub Group is not assigned to the Main L/R
outputs.
9.
Main L/R assignment button –
1001108-01-F
Indicates the Sub
–
Indicates the
–
Assigns and unassigns this Sub Group to the Main L/R outputs.
Press Menu
Sub Groups
Sub 1 Setup
Inputs 1-8
2
6
9
67
Touch FX Touch an
Masters FX Channel
1
3 4
5
7
8
Touch
Setup
