TouchMix™-30 Pro
User Manual
Firmware Version 1.0
TouchMix-30 Pro
1001108-01-A
*1001108-01*

Advertisement

Table of Contents
loading

Related Manuals for QSC touchmix-30 pro

Summary of Contents for QSC touchmix-30 pro

  • Page 1 TouchMix™-30 Pro User Manual Firmware Version 1.0 TouchMix-30 Pro 1001108-01-A *1001108-01*...

  • Page 2: Important Safety Instructions

    QSC authorized service station or QSC International Distributor. Failure to perform necessary repairs could lead to additional damage or to safety hazards. Failure to perform necessary repairs voids the limited warranty and QSC is not responsible for any injury, harm or related damages arising from any failure to perform those repairs.

  • Page 3: Maintenance And Repair

    Для ознакомления с условиями ограниченной гарантии, посетите страницу компании QSC Audio Products в интернете www.qsc.com www.qsc.com ‫ للمنتجات الصوتية عىل‬QSC ‫، قم بزيارة الموقع ال إ لك� ت و� ن ي ل� ش كة‬QSC‫للحصول عىل نسخة من الضمان المحدود الخاص بـ‬...

  • Page 4: Table Of Contents

    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii TouchMix-30 Pro™...
  • Page 5 QSC NXD Amplifier Settings . . . . . . . . . . . . . . . . . .
  • Page 6 TouchMix-30 Pro™ Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Netting Started .
  • Page 7 Sub Nroups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Sub Nroup −...
  • Page 8 TouchMix-30 Pro Block Diagram . . . . . . . . . . . . . . . . . .

  • Page 9: Touchmix-30 Pro

    Netting Started You just got your new TouchMix-30 Pro and can’t wait to try it out on your next show. But since TouchMix-30 Pro is a digital mixer there are lots of things you can do off-line to save time during setup and help you get acquainted with your mixer. We highly recommend spending a little quality time with the mixer before taking it to a show for the first time.

  • Page 10: Build A Mix Using Factory Presets

    • Omit Routing: When switched on, the scene will be recalled without making any change to routing such as subgroup assignments and pre/post selections. Your TouchMix-30 Pro is loaded with pre-defined scenes for various kinds of performances. You can find the one that’s most like the show you’ll be mixing and start there.

  • Page 11: Auxiliary Outputs

    Audio effects (FX) such as reverb, delay, chorus, pitch shift (pitch change) and pitch correct are essential in today’s audio production. The TouchMix-30 Pro has six multi-effects processors or “engines”. All of these processors may be configured to be one of six different effects including Lush Reverb, Dense Reverb, Chorus, Mono Delay, Stereo Delay and Pitch Shift.

  • Page 12: Name The Effects Channels (Or Mixes)

    Name the Effects Channels (or Mixes) In the middle of a show it’s easy to forget which effect was intended for what performers or instruments so this would be a great time to name the Effects Send channels. For example, you might name an FX channel “Voc Delay” or “Drum Rev”. FX Masters 1-8 FX 1 Setup...

  • Page 13: Pitch Correct

    Pitch Correct Pitch Correct Inputs 1-8 To assign Pitch Correct to a channel: In 1 Enable The Pitch Correct Effect is somewhat different than the Reverb, Delay, Chorus and Pitch Shift Effects. Pitch Correct can only be used on one input channel at a time and there is one Pitch Correct effect.

  • Page 14: Using The Fx Overview

    4. Effect Processor – Indicates the type of Effect currently being applied to the FX Mix. So that’s about it for effects. We worked hard on the TouchMix-30 Pro effects and know that they sound superb and will enhance your performances.

  • Page 15: Dca Nroups

    DCA Nroups A DCA groups faders together so the overall level of all the channels in the group can be controlled by a single DCA fader. A DCA fader does not change the position of any of the faders in the group. IMPORTANT!: Here is an important thing to know –...

  • Page 16: Save Your Ork As A Scene

    • Connect to a wireless router using a Wi-Fi USB Dongle • Connect to a wired network using the RJ45 connector and CAT-5 cable. *The TouchMix-30 Pro supports USB Wi-Fi adapters using the Realtek 8188eu chip-set. A compatible adapter is available from QSC Create ireless Network (TouchMix-30 Pro) This approach uses a Wi-Fi USB dongle to create an ad hoc network.

  • Page 17: Ireless Connection To Existing Network

    Connection to Existing Network When this method is used, TouchMix-30 Pro uses a wireless connection to an external router. Wi-Fi devices connect to TouchMix-30 Pro via the external router. Make sure a compatible USB Wi-Fi adapter is installed in one of the mixer’s USB ports.

  • Page 18: Ired Connection To A Network Or Router Using Automatic Ip Addresses

    5. Touch Apply Sound Check Before connecting anything, plug in your TouchMix-30 Pro and make sure that all the inputs and Auxiliary Outputs are muted. This will prevent uncontrolled feedback if a microphone is patched into a hot channel. Inputs 1-8...

  • Page 19: Qsc Nxd Amplifier Settings

    QSC NXD Amplifier Settings If you are using a QSC GXD amplifier, you can optimize the gain and sensitivity for use with your TouchMix-30 Pro. Refer to See "GXD Amp Settings" on page 51 Phantom Power (+48V) Most condenser microphones and some direct boxes require phantom power from the mixer. On TouchMix-30 Pro, phantom power may be turned on or off on a per channel basis.

  • Page 20: Auxiliary (Stage Monitor) Mixes

    Auxiliary (Stage Monitor) Mixes There are two general approaches to setting up stage monitor mixes: Input by Input With all the performers on stage, ask each performer in turn to play or sing just one thing (Kick, Snare, Guitar, Sax, etc). Ask each performer how much of that instrument they want in their monitor.

  • Page 21: Peq Tab

    PEQ Tab Six-band parametric EQ with High / Low-Cut filters and a Real Time Analyzer (RTA) This tab displays the six-band, parametric equalizer plus the Low and High-Cut Filters. The 6 bands of parametric EQ can be individually bypassed using the numbered buttons. Bands 1 and 6 may be switched from parametric to shelving operation. RTA On Touch the button to activate / deactivate a Real Time Analyzer display for the channel.

  • Page 22: Limiter Tab

    (USB) memory. The Preset Tab also includes factory voicings for QSC E-Series loudspeakers. These settings are also available for QSC PLD and GXD amplifiers. The E-Series voicings are intended for use with other amplifiers that lack DSP. An “X” suffix after the preset name indicates the preset is intended for use with a sub-woofer.

  • Page 23: Recording

    • For 44.1 kHz – Space required (in MB) = 10.6 x minutes x tracks It is good practice to have more disk space available than you need. If the drive is nearly full, TouchMix-30 Pro has to look for nooks and crannies of available space.

  • Page 24: Multi-Track Playback & Mix Down

    Multi-Track Recording The TouchMix-30 Pro is capable of recording 32 tracks of 32-bit, floating-point audio directly to a USB hard-drive (see above). Inputs 1 – 30 are the source for thirty of these tracks. Two additional tracks may be recorded from either the Main L/R output or Auxiliaries 13 & 14.

  • Page 25: Mix Down

    USB type-B connector attached to the “USB DAW” port of the mixer. To verify that your Mac is connected, open the Audio MIDI Setup utility on the computer (Finder > Applications > Utilities > Audio MIDI Setup). “QSC TM30 Pro” will appear in the Audio Devices window.

  • Page 26: Anti-Feedback System

    • Repeat until you have achieved sufficient system gain without feedback. Using the Feedback izard The tricky part is to identify the feedback frequencies. Fortunately, you don’t need to identify them because the TouchMix-30 Pro has built-in tools to do that for you. Here’s how to use those tools.

  • Page 27: More About The Anti-Feedback System

    Real Time Analyzer (RTA) An audio Real Time Analyzer breaks the spectrum into frequency bands – 1/3 octave bands for the TouchMix-30 Pro RTA – and displays the amplitude of the signal in each band. It is useful for visualizing the frequency balance of a signal and for identifying feedback frequencies.

  • Page 28: Mutes

    Copy & Paste The TouchMix-30 Pro has a powerful but simple copy and paste function that is operated by the U7 (copy) and U8 (paste) buttons. Copy and Paste is context sensitive so that what you are looking at is what will be copied. Only like things may be copied and pasted from and to each other. For example, a PEQ cannot be pasted to a GEQ.

  • Page 29: Patch Matrix

    The TouchMix-30 Pro has audio inputs plus a set of graphical controls and processing for each audio channel. Let’s call these “Inputs” and “Channels”. By default, the audio for Input 1 is controlled and processed by Channel 1, Input 2 is controlled and processed by Channel 2 and…, well you get the idea.
  • Page 30 To access the Patch Matrix: Patch Matrix Menu NOTE!: When the Patch Matrix is loaded for the first time after the mixer was powered on, it may take a few moments to display. The Patch Matrix displays the Analog Inputs across the top of the screen and the Destination Channels down the right side. Connection is indicated with lines and a blue circle.

  • Page 31: Matrix Mixing

    Before proceeding with the Tuning Wizard, listen to your system in the room using material with which you are familiar. Many contemporary loudspeaker systems – especially powered loudspeakers such as the QSC K, KW and KLA series – have been carefully tuned by design and will sound very good with little or no additional equalization.
  • Page 32 . The mixer produces the test signal and captures the measurement data. NOTE!: Each output of the TouchMix-30 Pro actually has two graphic equalizers. One is used by the Tuning Wizard to apply corrections based on the measurement data. Settings for this equalizer are indicated by the outlined or “ghost” fader caps on the GEQ screen. The other equalizer may be adjusted by the user or a target tuning can be applied by the wizard.

  • Page 33: User Buttons

    Overview tab and hold a User Button for two seconds. Touch “Yes” and the User Button will now take you to the Channel 12 Overview screen no matter where you are. MIDI Control A USB-over-MIDI device such as a footswitch may be used to control some TouchMix-30 Pro functions. MIDI Control is similar in function to User Buttons. MIDI 1 MIDI Setup 1.

  • Page 34: Security

    4. To assign a function to the "learned" button: Security The TouchMix-30 Pro has multi-level security that allows you to assign passwords to various levels of functionality. You can give users access to only the functions they are authorized to use.

  • Page 35: Monitor

    Monitor Monitor The monitor output is most commonly used to feed a pair of monitor loudspeakers. Source Main L/R To adjust Monitor level: Use the Master Rotary Encoder. Monitor Delay feet 11.3 Close Touch or push to dismiss the pop-up. Monitor 10.0 There are additional controls for the monitor output.

  • Page 36: Touchmix-30 Pro

    Reference The information provided in this section gives you a detailed description of the screens and controls for the TouchMix-30 Pro and the TouchMix-30 Pro remote apps. The screen shots provided are taken from the TouchMix-30 Pro iPad App, and because of a different screen size, may appear slightly different than the TouchMix-30 Pro screens.

  • Page 37: Device Settings

    1 Drives must be formatted using the FAT32 file system. A FAT32 format utility is accessible from the Recording Setup screen. For best results use 7200 RPM, USB 3 hard drives or high- speed SSD. Drive performance is critical for recording. For more information and to see a list of qualified drives, visit qsc.com. At this time, the TouchMix-30 Pro-30 supports playback of MP3 digital audio files from the USB port, and exporting the recorded 2-Track files to the MP3 format.

  • Page 38: Touchmix-30 Pro Specifications

    TouchMix-30 Pro Specifications Parameter Specification Display 10” (254mm) diagonal, 1024 x 600 pixel, color TFT, capacitive multi-touch sensing Inputs 32 Total 24 Mic/Line, 20 XLR, 4 XLR combo 6 Line, balanced, 1/4” TRS + top panel 1/8” (3.5 mm) stereo...

  • Page 39: Tm-30 Pro Feature List

    Phantom Power 48 v, all mic and talkback inputs, individually switchable per input Optional Accessories TouchMix-30 Pro Tote ; TouchMix-30 Pro Dust Cover; TouchMix-30 Pro Rack Kit; TouchMix-30 Pro Tablet Support Stand Regulatory Approvals UL, CE, FCC (Class B), RoHS TM-30 Pro Feature List Alphabetical list of some of the main features on the TM-30 Pro.
  • Page 40 Feature Navigation Info System Topic Effects to Auxes Select an Aux on left of screen > Select FX Masters FX Masters, Aux Sends FX Wizard Menu > FX Wizard Wizards, FX Wizard Gain Wizard Menu > Gain Wizard Wizards, Gain Wizard Languages Info >...

  • Page 41: Home Screen

    Home Screen Home Home (if needed) Nav Strip The Nav Strip provides the primary means of navigating between fader banks. In addition, it provides an overview of all Inputs 1-8 Inputs 9-16 Inputs 17-24 Stereo In/2-Trk FX Masters Aux Out 1-8 Aux Out 9-14 Sub Groups DCA Groups...

  • Page 42: Input Channels

    Input Channels Input Channel − Overview Select Select Select Home an Input Overview Channel Provides a single-screen view of frequently used controls Bank and indicators for the input channel. 1. Overview tab – Selects the Channel Overview screen. Inputs 1-8 In 1 Overview 2.
  • Page 43 TouchMix-30 Pro top panel. Aux 5 26. Nav Strip – Touch to select a fader bank. The Aux 6 Aux 6 TouchMix-30 Pro uses the first three fader banks for Aux 7 input channels 1–8, 9–16, and 17-24, respectively. Aux 7 Aux 8 •...

  • Page 44: Input Channel − Eq

    Input Channel − EQ Touch a Touch an Touch the Home Channel Input Bank EQ Tab Controls and displays the settings for the Input Channel Selector equalization. 1. EQ tab – Selects the EQ screen. Inputs 1-8 In 1 2. EQ In – Engages / disengages the equalizer. Inputs 1-8 3.

  • Page 45: Input Channel − Compressor

    Input Channel − Compressor Touch Touch Touch Home an Input Comp Channel The Compressor controls the dynamic range of a signal Bank above a set Threshold. 1. Comp tab – Selects the Compressor screen. Inputs 1-8 In 1 Comp 2. Comp In / Out switch – Engages and disengages Inputs 1-8 the compressor.

  • Page 46: Input Channel − Nate

    Input Channel − Nate Touch Select Touch a Home an Input Gate Channel The Gate passes audio above a set Threshold, and Bank attenuates audio below the Threshold. 1. Nate tab – Selects the Gate Screen. Inputs 1-8 In 1 Gate 2.

  • Page 47: Input Channel − Fx Sends

    Input Channel − FX Sends Touch Touch Touch a Home an Input Channel Controls how much of the Input channel’s audio is sent Bank FX Tab to the FX devices. 1. FX tab – Selects the FX Sends screen. Input 1-8 In 1 2.

  • Page 48: Input Channel − Aux Sends

    Input Channel − Aux Sends Touch Touch an Touch a Home Auxes Input Bank Channel Auxiliary outputs are used to create a mix for stage monitors, in ear monitors, remote speakers or video / broadcast. There are 14 auxes and they may be Inputs 1-8 linked for stereo.

  • Page 49: Input Channel − Presets

    Type Preset Name User preset libraries. Assorted Acoustic Guitar Ele Gtr Dyn Blues Aux 4 • Factory Presets – A library of QSC designed input- Aux 4 Bass Banjo Ele Gtr Dyn Clean Drums Electric Guitar Ele Gtr Dyn Metal Main channel presets.

  • Page 50: Input Channel − Setup

    Input Channel − Setup Touch Touch the Touch a Home an Input Setup Channel Channel Setup is provided for all input channels. Line Bank input channels 25 - 30 do not have Phantom power controls. Inputs 1-8 In 1 Setup 1.

  • Page 51: Output Channels

    3. Pick-off point – (Auxes only) Determines where Aux 2 Aux 2 the signal for the output channel is taken. Tuned for QSC E10 Monitor Mute Groups Aux 3 4. Delay – Controls and indicates the amount of delay AUX Sends Aux 3 (up to 100 msec.) applied to the signal.

  • Page 52: Output Channel − Neq

    Output Channel − NEQ Touch Touch an Touch Home an Aux GEQ Tab Controls and displays the settings for Main or Auxiliary Bank Channel output graphic equalization. 1. NEQ tab – Selects the GE Q screen. Aux Outputs1-8 Aux 1 2.

  • Page 53: Output Channel − Peq

    Output Channel − PEQ Touch an Touch an Touch the Home Aux Bank PEQ Tab Controls and displays the settings for the Main or Channel Auxiliary output parametric equalization. 1. PEQ tab – Selects the PEQ screen. Aux Outputs1-8 Aux 1 Inputs 1-8 2.

  • Page 54: Output Channel − Comp/Limiter

    Output Channel − Comp/Limiter Touch Aux Touch Touch the Home an Aux Limiter When set as a Limiter, prevents the audio level from 1–8 or 9–14 Channel exceeding a preset threshold. 1. Comp / Limiter tab – Selects the Comp /Limiter screen.

  • Page 55: Output Channel − Anti-Feedback

    Output Channel − Anti-Feedback Press Touch an Touch Touch an Anti- Home Aux Channel Anti-Feedback Aux Bank Available on the Main L/R and Aux 1 - 14 outputs, Feedback or Main these narrow, cut-only filters are used for dealing with feedback. Aux Outputs1-8 Anti- Anti...

  • Page 56: Output Channel − Presets

    Aux 1 Main storage destination. 4. Factory presets list – Displays a list of factory programmed presets. Voicings for QSC passive loudspeakers are provided. Reset sets all output channel’s parameters to their factory default state. Main The Reset preset is at the bottom of the list, scroll down to see.

  • Page 57: Output Channel − Setup

    The selections are: Pre Fdr (default)/ Post Fdr / Pre Dyn / Pre All. 6. QSC Amplifier and Speaker Settings – Displays tools to assist in optimizing gain structure and other parameters for selected QSC amplifiers and loudspeakers.

  • Page 58: Output - Speaker Settings

    Press Touch Output Output Home K Series Provides help in properly adjusting QSC K, KW and KLA Bank Channel powered loudspeakers when used with the TouchMix. 1. Select Speaker – Touch the button that Aux Out 1 - 8 Aux 1...

  • Page 59: Nxd Amp Settings

    Touch an Touch an Press Touch Output Output Home Amplifiers Provides help in properly adjusting QSC GXD Amplifier Bank Channel when used with the TouchMix. Aux Out 1 - 8 On the NXD Amplifier Aux 1 Ampli ers Inputs 1-8 1.

  • Page 60: Aux Overview

    Aux Overview Press Aux Provides an overview of all 14 Aux mixes. The Aux Send and Output levels may be adjusted on screen or, for greater precision, by touching turning the Master Control or using the buttons on your tablet device.

  • Page 61: Sub Nroups

    Sub Nroups Sub Nroup − Overview Press Touch Sub Touch a Sub Touch Home Group Bank Group Overview Tab Provides a single-screen view of frequently used controls and indicators for the Sub Groups. 1. Overview tab – Selects the Sub Group Overview Sub Groups Sub 1 Overview...

  • Page 62: Sub Nroup − Peq

    Sub Nroup − PEQ Press Touch a Sub Touch a Touch the Home Group Bank Sub Group EQ Tab Controls and displays the settings for the Sub Group parametric equalization. 1. EQ tab – Selects the PEQ screen. Sub Groups Sub 1 2.

  • Page 63: Sub Nroup − Compressor / Limiter

    Sub Nroup − Compressor / Limiter Touch Touch a Touch the Home an Input Channel Comp Tab The Compressor reduces the dynamic range of a signal Bank above a set Threshold. When set as a Limiter, prevents the audio level from exceeding a pre-set threshold. Sub Groups Sub 1 Comp...

  • Page 64: Sub Nroups − Fx Sends

    Sub Nroups − FX Sends Touch Sub Touch Touch Home Groups Channel FX Tab Controls how much of the Sub Group audio is sent to Bank the FX devices. 1. FX tab – Selects the FX Sends screen. Sub Groups Sub 1 2.

  • Page 65: Sub Nroup − Auxes

    Sub Nroup − Auxes Touch the Touch a Touch the Home Sub Groups Sub Group Auxes Sub Groups may be sent to Auxiliary Mixes. An Aux may Bank Channel be used to output a single Sub Group or as a matrix to mix multiple Sub Groups.

  • Page 66: Sub Nroup − Presets

    Sub Nroup − Presets Touch a Press Touch Sub Touch Sub Group Home Groups Presets Recall presets for the selected Sub Group channel. Channel 1. Presets tab – Selects the Presets screen. 2. Current Preset – Displays the name of the currently active preset (if any).

  • Page 67: Two-Track Playback

    Two-Track Playback Touch Touch Press Rec/ Touch Recording Stereo Play Overview Mode Two-Track Playback − Overview Provides a single-screen view of frequently used Touch Touch Touch controls and indicators for the MP3 Audio Player and Press Rec/ Touch Touch Recording Multitrack Multitrack the 2-Channel Playback channel.

  • Page 68: Two-Track Playback - Eq

    Touch Touch Two-Track Playback – EQ Press Rec/ Touch Recording Stereo Play 1. EQ tab – Displays the Audio Player EQ controls. Mode 2. PEQ switch – Enables (In) / bypasses (Out) the equalizer. Touch Touch Touch 3. RTA On – Enables / disables the Real Time Press Rec/ Touch Recording...

  • Page 69: Two-Track Playback - Audio Player

    Two-Track Playback – Audio Player Touch Touch Touch Press Rec/ Recording Stereo Audio Play Plays MP3 audio files from a USB memory device. Mode Player NOTE!: Make sure the Sample Rate set in Audio Recording Stereo MP3 Rec/ Play Mode USB Drive Playback Player the Mixer Setup matches the sample rate of...

  • Page 70: Two-Track Playback − Auxes

    Two-Track Playback − Auxes Touch Touch Press Rec/ Touch Recording Stereo Play Auxiliary outputs are used to create a mix for stage Mode monitors, in ear monitors, remote speakers or video / broadcast. There are 14 auxes and they may be linked for stereo.

  • Page 71: Two-Track Playback − Presets

    Two-Track Playback − Presets Touch Touch Press Rec/ Touch Recording Stereo Play Presets Recall presets for the MP3 Stereo and the 2-Track Playback. Mode 1. Presets tab – Selects the Presets screen. 2. Current Preset – Displays the name of the Touch Touch Touch...

  • Page 72: Two-Track Playback − Setup

    Two-Track Playback − Setup Touch Touch Press Rec/ Touch Recording Stereo Play Setup Rename the FX Master channel, and assign the Mode channel to Mute and DCA Groups 1. Setup tab – Selects the Setup screen. Touch Touch Touch 2. Name field – Touch the Name to display a Press Rec/ Touch Touch...

  • Page 73: 2-Track - Playback

    2-Track – Playback Touch Touch Touch Touch Press Press Stereo In / Recording Multitrack Multitrack Home Rec/Play Multitrack mode plays back audio recorded on the USB 2-Trk Mode USB Drive drive. Multitrack DAW mode plays back tracks from a Core Audio compliant computer. Stereo In/2-Trk Recording Multitrack...

  • Page 74: Fx Masters

    FX Masters Touch the Touch the Touch an Home FX Masters Overview FX Channel Bank FX Master − Overview FX Masters Overview FX 1 Provides a single-screen view of frequently used controls Inputs 1-8 and indicators for the FX channel. Main Mix Scene: Overview...

  • Page 75: Fx Masters − Eq

    FX Masters − EQ Touch an Touch FX Touch the Home Masters EQ Tab Controls and displays the settings for the FX Master Channel channel equalization. FX Masters 1. EQ Tab – Selects the FX Master EQ screen. FX 1 Inputs 1-8 2.

  • Page 76: Fx Master − Setup

    FX Master − Setup Touch an Press Touch FX Touch Menu Masters Setup Rename the FX Master channel, and assign the channel Channel to Mute and DCA Groups 1. Setup tab – Selects the Setup screen. 2. Name field – Touch to display a keyboard and enter a name for the channel.

  • Page 77: Fx Overview

    FX Overview Press Touch FX Provides an overview of the channel FX Send and Return Menu Overview levels. FX sends and FX Master levels may be adjusted by touching (selecting) the control then using the Master Encoder or the Nudge buttons on a tablet device. NOTE!: Only Input and Sub Nroup banks are selectable on the Nav Strip.

  • Page 78: Izards

    izards Press Touch Wizard FX Wizard FX izard The FX Wizard aids in selecting and routing effects. 1. FX1 - 6 tabs – Selects one of six FX processors. NOTE!: The Source, Type, and FX Preset windows provide a means of selecting an Effect based on what the source is.

  • Page 79: Tuning Izard

    Tuning izard Touch Touch an Touch Home Tuning Output The Room Tuning Wizard assists in adjusting output Wizard equalization 1. Tuning Output – Displays the system and friendly Touch name of the output being tuned. Press Tuning 2. Restart – Go back and start over. Wizard Wizard 3.

  • Page 80: Fx Processor

    FX Processor Touch the Touch Touch an Touch the Touch Home FX Masters Effect Pull- FX Channel Effect Tab Chorus Bank Down FX Processor – Basic Chorus The Chorus FX Varies the pitch of a signal at a steady rate FX Masters FX 1 E ect...

  • Page 81: Fx Processor - Dense Reverb

    FX Processor – Dense Reverb Touch the Touch Touch Touch an Touch the Home FX Masters Effect Dense FX Channel Effect Tab The Dense Reverb (presets with a “D” suffix) is a model Bank Pull-Down Reverb of a DSP reverb with more dense reflections that some may find more representative of actual acoustic spaces.

  • Page 82: Fx Processor - Lush Reverb

    FX Processor – Lush Reverb Touch the Touch Touch Touch an Touch the Home FX Masters Effect Lush FX Channel Effect Tab Reverb presets with an “L” suffix use a DSP reverb model Bank Pull-Down Reverb with a more “lush” character. 1.

  • Page 83: Fx Processor - Mono And Stereo Delay

    FX Processor – Mono and Stereo Delay Touch Touch the Touch Touch an Touch the Stereo Home FX Masters Effect These effects delay the audio signal to create echo and FX Channel Effect Tab or Mono Bank Pull-Down similar effects. Controls for the stereo delay may be Delay linked or operated independently.

  • Page 84: Fx Processor - Pitch Shift

    Touch the Touch FX Processor – Pitch Shift Touch an Touch the Touch Home FX Masters Effect FX Channel Effect Tab Pitch Shift The Pitch Shift raises or lowers the pitch of an audio Bank Pull-Down signal by a fixed interval. In addition, the signal can be delayed from the original.

  • Page 85: Fx Processor - Pitch Correct

    Touch FX Processor – Pitch Correct Touch an Touch Home an Input In Channel the FX Tab Corrects intonation of the audio signal. Bank IMPORTANT!: Pitch-Correct may be Input 1-8 In 1 enabled/disabled by User Buttons without Inputs 1-8 regards to the position of the Enable Main Mix Scene: button on this screen.

  • Page 86: Security

    Aux 13 Aux 13 Aux 14 Mute NOTE!: Forgotten Administrator Password? Aux 14 Contact QSC Technical Support. Touch Press Touch Security Menu Security 5. Set Passwords – Enter a password in a text field to Settings secure the associated functions.

  • Page 87: Miscellaneous Features

    • Device Settings – Available on tablets only. Aux 9 Touch this control to select a mixer when more Aux 10 Remote MIDI Setup Language than one TouchMix-30 Pro mixer is connected to Control Settings Aux 10 Aux 11 the network. (Device Settings on page Aux 11 8.

  • Page 88: Remote Control Settings

    Touch Remote Control Settings Press Remote Menu Allows or restricts access to mixer functionality by device. Control NOTE!: When a remote device is set to Remote Menu Control Personal Monitor Mix, the Cue and Mute Main Mix buttons are not available on the Aux-Mix- Scene: Remote Control Settings Default...

  • Page 89: User Buttons

    Touch User Buttons Press User Menu Assign alternate functions to the User Buttons. Buttons User buttons defaults: • U1 – Navigate Left User Menu Buttons • U2 – Clear Clip Main Mix Scene: User 1 User 2 User 3 User 4 User 5 User 6 User 7...

  • Page 90: Mixer Setup

    15. Reset Mixer – Resets all mixer controls to factory default. This does not erase any user presets on the mixer or on a USB drive. 16. Software Version Label – Displays the version number of the currently installed firmware. 17. Upgrade – Begins the process of upgrading mixer software. Before starting, visit www.qsc.com for upgrade instructions and to download the latest firmware version.

  • Page 91: Phantom Power

    Phantom Power Press Mic 48V Supplies +48 VDC to XLR Inputs including Talkback. 1. Reset – Returns all settings to factory default (all phantom power off). 2. Input Channel buttons – Touch to enable or disable phantom power for the channel. 3.

  • Page 92: Mute Nroups

    Mute Nroups Press Mute Groups Mute Groups provide a means of muting multiple inputs and outputs from a single control. Mute Groups About Mute Nroups Main Mix Scene: Mute Groups Default When a channel is in one or more Mute Groups, all Mute Joe’s Monitor Groups containing the same channel and the Channel Edit...

  • Page 93: Record / Playback (Multitrack Usb Drive)

    FAT32 to work with TouchMix-30 Pro. Drive performance is critical for recording. For more information and to see a list of qualified drives, visit qsc. com. At this time, the TouchMix-30 Pro does not support importing or re-importing digital audio files that have been created or edited on another device.

  • Page 94: 2-Track − Recording

    Recording Rec/ Multitrack Play Mode IMPORTANT!: The TouchMix-30 Pro DAW interface is compatible with Core-Audio compliant computers only. 1. Track button – Touch the Track button to select a DAW track as the source for the channel. 2. DA – Indicates if the mixer is receiving audio from the DAW (Connected) or not (Not Receiving Audio).

  • Page 95: Real-Time Analyzer (Rta)

    Real-time Analyzer (RTA) Press A maximum of two RTA displays are available at a time on any combination of a mixer and tablet devices. Not available on a phone-type device. 1. The system and friendly name for the RTA Source. 2.

  • Page 96: Dca Nroup Assignments

    DCA Nroup Assignments Touch Press Touch a Home DCA Groups are used to vary the gain of several Groups channels at once from a single fader without changing the position of the channel faders. DCA groups also DCA Groups DCA 1 include a mute function.

  • Page 97: Midi Setup

    MIDI 2 MIDI 3 MIDI 4 MIDI 5 MIDI 6 MIDI 7 MIDI 8 QSC has verified proper operation with these USB MIDI Default Drums Not in use Not in use Not in use Not in use Not in use...

  • Page 98: Talkback / Noise

    Talkback / Noise Press Touch Menu Talkback This screen controls the routing and level of Talkback and Noise. 1. Reset button – Restores factory defaults for the Menu Talkback Talkback / Noise Generator. 2. Assignment buttons – Select the destination for Main Mix Scene: Talkback / Noise Generator...

  • Page 99: Network Setup

    Network Setup ireless Network Setup Main Mix Scene: Network Setup Default IMPORTANT!: Requires a compatible, Joe’s Monitor USB Wi-Fi dongle (visit www.qsc.com for Mixer Name: My TM-30 Main Aux 1 recommendations) or an Ethernet Wi-Fi Aux 2 Edit Settings for:...

  • Page 100: Phones And Monitor

    Phones and Monitor Press Press Phones and Monitor Level Control Phones Monitor Phones (1) and Monitor (2) Cue Level – Control the level of the signal on the Phones and Monitor outputs. Phones Monitor NOTE!: There are additional controls associated with the Monitor system. See the Mixer Setup topic for details.

  • Page 101: Recording Setup - Multitrack Usb

    Recording Setup – Multitrack USB Recall, initiate, and manage Multitrack recording sessions. Press Touch Touch Touch Touch New Touch Scroll down for Recalling a session. Rec / Recording Multitrack Recording Session Rename 1. Current Session – Displays the name of the Play Mode USB Drive...

  • Page 102: Aux Mix On Faders

    Aux 3 Aux 4 selected. Aux 4 Aux 5 TouchMix-30 Pro Auxes are doing double duty as Mix Aux 5 Matrices. A Mix Matrix lets the operator take existing Aux 6 main, auxiliary and sub group mixes and create a new...

  • Page 103: Patch Matrix

    Patch Matrix Touch Press Patch Menu Manages connections between physical inputs and on- Matrix screen channels 1. Preset – Displays the name of the current preset. Menu Patch Matrix ”Default routing” is the Reset or factory default Main Mix Preset. Scene: Patch Matrix Default...

  • Page 104: Copy And Paste

    Copy and Paste The TouchMix-30 Pro has a powerful but simple copy and paste function that is operated by the U7 (copy) and U8 (paste) buttons. Copy and Paste is context sensitive so that what you are looking at is what will be copied. Only like things may be copied and pasted from and to each other. For example, a PEQ cannot be pasted to a GEQ.
  • Page 105 hat’s Displayed hat will be copied & pasted Output Channel Limiter Tab All channel Limiter parameters Output Channel FX Tab All channel FX send levels Output Channel Aux Tab All channel Auxiliary Send levels and Pan positions Output Channel Setup Tab Recording Arm, Polarity, Delay, Digital Gain, Group assignments FX Channel Overview Tab Current Preset, EQ, Pick-Off Point, Group Assigns, Polarity...

  • Page 106: Dimensions

    Dimensions 435 mm 17.1 in 428 mm 16.9 in 191 mm 7.5 in 191 mm 7.5 in 459 mm 18.1 in 1001108-01-A...

  • Page 107: Touchmix-30 Pro Block Diagram

    TouchMix-30 Pro Block Diagram © 2016 QSC, LLC Mic/Line Main L/R Output Low Cut High Cut Meter From DCA Masters Main Left Meter 18 dB/Oct 18 dB/Oct Notch Filters 1/3 Oct GEQ Comp 1/3 Oct GEQ Delay Over Ch Fader...
  • Page 108 © 2016 QSC, LLC. All rights reserved. QSC, the QSC logo, and TouchMix-30 Pro are registered trademarks of QSC, LLC in the U.S. Patent and Trademark office and other countries. iPad, iPhone and iOS are trademarks of Apple Inc., registered in the U.S. and other countries. All other trademarks are the property of their respective owners.

Table of Contents
