Phantom Power

Supplies +48 VDC to XLR Inputs including Talkback.
1. Returns all settings to factory default
Reset –
(all phantom power off).
2. Input Channel buttons –
to enable or disable phantom power for the
channel.
3.
Rear Panel View XLRs –
to enable or disable phantom power for the
channel.
NOTE: Phantom power may also be
controlled from the Setup screen of each
input channel.
NOTE: It is good practice to turn off
phantom power when connecting or
disconnecting an input. "Hot patching" a
device can cause severe transients and
potentially damaging current surges.
1001108-01-F
Touch
Touch
97
Press
Mic 48V
