Teldat S.A.
DIN rail mount: Position 1
Fig. 7:
DIN rail mount: Position 2
Fig. 8:
3.2.2 Installing the Protector
The transparent protector protects the device connectors from being manipulated while the device is operating. The
protector is not mounted on the device in the package; it is a separate piece.
The following figure shows you how to attach the protector on the device:
Regesta-PRO-ER
3 Components and Power Supply
11
