2.3 Power source

The SDE is powered by means of two internal AC/DC sources. The SDE has two power inputs and two power sup-
plies that operate simultaneously. It can operate each one individually or both at the same time. If SDE is powered by
the two power supplies and one of them fails, the other one acts as a backup.
Warning
The equipment must be used with the power supply provided by the manufacturer.
Workplace Conditions. Main Characteristics
• Avoid humid and/or dusty locations.
• Avoid prolonged exposure to sunlight and other heat sources. The device should not be placed amongst papers,
magazines or other elements that could hinder natural air circulation.
• The device should not be placed close to strong electromagnetic fields, e.g., by speakers, motors, etc.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.

2.4 Connecting the data

The SDE has the following data connections.

2.4.1 SFP ports

The SDE incorporates 4 10Gbit SFP ports.
Fig. 9: SFP ports (with connected transceivers)
All OSDx interfaces are bridged by default. The system tries to obtain the IP address via DHCP. If no IP address is
obtained, 192.168.1.1 will act as default.
The SSH server is enabled in SDE. Default credentials are:
user: admin
password: admin

2.4.2 Connecting for configuration

To access the SDE device via the local console, a monitor and a keyboard can be connected to it (using the VGA
and USB ports, respectively)
Default credentials are:
user: admin
password: admin

2.5 Factory reset

To perform a factory reset and restore the default configuration, follow these steps:
(a) Enter SDE's local console.
(b) Type the following command: factory-reset now
