7.1.1.

Opening the cable cover

1. Unscrew the thin headless screws of the cable cover
2. Carefully remove the cable cover.
NOTICE
Closing the cable cover
Please refer to section 13.2.8 Attach the cable cover .
DLT-V72 Series User Manual V2.70
with an Allen wrench, size
Prevent system malfunction and property damage
Improper opening of the cable cover can impair the function of the
entire DLT-V72 system.
1. The cable cover is only permitted to be removed by qualified
expert personnel and only for the duration of servicing work.
2. Switch off the DLT-V72 before removing the cable cover.
3. The device has to be fully deenergised.
4. No objects or liquids are permitted to enter the opened DLT-
V72.
5. The device is only permitted to be operated again once the
cable cover is properly sealed again; only then is the protection
class guaranteed.
3.
