- Page 1 Advantech-DLoG DLT-V6210 ∕ Manual DLT-V6210 Industrial PC Manual V1.00 www.advantech-dlog.com...
- Page 2 ® and RAM Mount™ are both trademarks of National Products Inc., 1205 S. Orr Street, Seattle, WA 98108. DLT-V6210 devices can be delivered with or without preinstalled software. For devices with preinstalled software observe the associated license agreements. We recognize all national and international trademarks and product names.
-
Page 3: Table Of Contents
16.1.2. EMC EU ................. 54 8.1.1. Installing the disconnecting device ........23 16.2. FCC USA/CAN ............... 55 8.1.2. Installation of DLT-V6210 on vehicles ........24 16.3. RED (Radio Equipment Directive) 2014/53/EU ...... 57 8.2. Preparations ................25 16.4. CE marking ................58 8.2.1. -
Page 5: Available Dlt-V6210 Manuals
DLT-V6210 Pay attention to these manuals because they help avoid hazards, reduce repair costs and downtimes, and increase the reliability and service life of DLT-V6210. Keep the manuals for future use. Please contact DLoG GmbH if you require additional information or clarification. You can find the contact address in section Technical customer support. -
Page 6: Design Elements In The Manual
Available DLT-V6210 manuals 1.1. Design elements in the manual Personal injury Information with regard to personal injury is shown in this manual as follows (signal words for indicating risk level): DANGER / WARNING / CAUTION DANGER means that death or severe bodily injury will occur if this information is not observed. -
Page 7: Functional Description
(e.g. logistics, warehouse, manufacture site). Any other or additional usage beyond this shall be deemed as improper usage. The user / operator of DLT-V6210 is solely responsible for any resulting damage. This also applies to any unauthorized modifications made to this device. -
Page 8: Mount, Operate And Service The Device Correctly
Find details on www.advantech-dlog.com. LCD display The LCD display of DLT-V6210 series fulfills the highest quality standards and was inspected for pixel defects. However, due to technological reasons pixel defects can occur. This is not a malfunction; it is a part of the technical specifications. -
Page 9: Functional Overview
Functional description 2.4. Functional overview DLT-V6210 front side DLT-V6210 back side © by DLoG GmbH DLT-V6210 Manual V1.00 Page 9 / 61... -
Page 10: Device Identification/Name Plate
Functional description 2.5. Device identification/name plate The name plate is located on the rear side of DLT-V6210. It must remain legible at all times for the purpose of identifying the device. Do not damage the name plate or remove it from the device. -
Page 11: Technical Data
IK08 (5 joule) according to ECN62262 Resistance Mechanical properties Chemically strengthened soda lime glass Chemical resistance Alcohols, Dilute Acids, Dilute Alkalis, Esters, Hydrocarbons, Ketones, Household Cleaning agents (according to DIN 42 115 PartIII) © by DLoG GmbH DLT-V6210 Manual V1.00 Page 11 / 61... -
Page 12: Internal Speaker, Sound
3.3. Internal speaker, sound DLT-V6210 is equipped with an internal speaker as standard (2 W). The system messages from the industrial PC are output via this speaker. The internal speaker can be configured in the audio settings of operating system in question. -
Page 13: Unpacking, Transport And Storage
Transport WARNING Risk of injury due to weight and sharp-edged parts. DLT-V6210 can fall down and cause injuries due to its weight. The strain relief rail can have sharp edges and cause cutting injuries. Always hold DLT-V6210 by the housing with both hands. -
Page 14: Storage
Place devices front-to-front in this case. The VESA mounting point on the rear side of the device can damage the touchscreen of another device. Use protective material (non-flammable!) between the devices as precaution. Page 14 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 15: Configuration With Mdevice
These instructions are directed to skilled personnel. Only qualified skilled personnel (e.g. IT personnel with good knowledge of PCs, operating systems and wireless networks) may configure DLT-V6210. If DLT-V6210 is incorrectly configured, the DLoG GmbH warranty for this device will be void. Start MDevice ... -
Page 16: Wi-Fi Configuration
EIRP (Equivalent Isotropically Radiated Power), in the 2.4 GHz frequency band is set at 20 dBm (100 mw). Set the transmitting power of the Advantech-DLoG antenna so that the permitted EIRP limit value is complied with. Examples worldwide:... -
Page 17: Electromagnetic Radio Frequency Energy
Do not use DLT-V6210 near pacemakers. Always keep a distance of at least 20 cm between a pacemaker and DLT-V6210 to reduce the risk of interference. Before using the device please obtain information about the use of the device within certain areas (e.g. -
Page 18: Mechanical Installation
These mounting instruction are directed to skilled personnel. Only qualified skilled personnel may perform the mechanical installation work on DLT-V6210. If DLT-V6210 is incorrectly mounted, any DLoG GmbH warranty for this device will be void. 7.1.1. Correct installation location WARNING Risk of injury and damage due to improper deployment location. -
Page 19: Secure Attachment
Do not open or modify DLT-V6210. Risk of injury due to weight and sharp-edged parts. DLT-V6210 can fall down and cause injuries due to its weight. The strain relief rail can have sharp edges and cause cutting injuries. ... -
Page 20: Recommended Sequence For The Mechanical Installation
Requirement: The installation location / vehicle must be prepared (e.g. connection to the ignition, correct voltage, etc.) We recommend the following sequence for the installation: Determine a suitable mounting position for DLT-V6210. Secure device mounting at the vehicle/targeted object (RAM Mount etc.). Connect external accessories to DLT-V6210. -
Page 21: Attach The Mounting With The Vesa Mounting Hole Pattern
Attach the mounting with the VESA mounting hole pattern The back of the DLT-V6210 has a VESA compatible 75 x 75 mm mounting hole pattern. It is used to attach VESA compatible mountings to mount the vehicle docking station at the deployment location. - Page 22 Washer spring A6 DIN128 FSt galvan. Screw Cyl.int.hex DIN912 M6x16 V2A Screw Cyl.int.hex DIN912 M6x16 V2A Washer ISO 8738 (DIN 1440)-A6-A2 Washer ISO 8738 (DIN 1440)-A6-A2 Washer spring A6 DIN128 FSt galvan. Page 22 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH...
-
Page 23: Electrical Installation, Cable Connection, Cable Cover
The operation of electrical equipment at locations where flammable gases or vapors are present poses a safety hazard. Turn off DLT-V6210 when you are near gas stations, fuel depots, chemical plants or places where blast might take place. © by DLoG GmbH DLT-V6210 Manual V1.00... -
Page 24: Installation Of Dlt-V6210 On Vehicles
Installation of DLT-V6210 on vehicles DANGER Electrical shock due to insufficient EMERGENCY shut-off switch. If the EMERGENCY-OFF switch of the vehicle does not switch off DLT-V6210, there is a risk of electrical shock. Install DLT-V6210 and the EMERGENCY-OFF switch so that DLT-V6210 also switches off when the EMERGENCY-OFF switch is operated. -
Page 25: Preparations
Electrical installation, cable connection, cable cover 8.2. Preparations Lay out all cables which are ready to be connected to DLT-V6210. Select the appropriate slot on the connector panel of DLT-V6210. Check and test which order of the cables routing is the best to fit in the cable compartment. -
Page 26: Components
Press the plugs of the cable grommet into the holes of the frame. If there’s no cable in the compartment, please put dummy grommet into it. Fig. 8.3: Example - 2 cables with cable grommets and 5 dummy grommets inserted Page 26 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 27: Power Cable, Grounding
DLT-V6210 may only be connected to a SELV circuit (Safety Extra Low Voltage). The SELV circuit is a secondary circuit that is designed to protect the voltage from exceeding the safe value when operation runs correctly or a single error occurs. - Page 28 CPU. All cable shields and the housing are connected to shield ground. The chassis of some forklifts is on DC+. This means that DLT-V6210 chassis is also on DC+. Short circuits can arise when, for example, the ground potential of a peripheral device is on DC-.
-
Page 29: Plugging In And Screwing On The Power Supply Cable
(from inside to outside): Place “toothed washer“ first (internal). Then put the “Ring Tongue of the power supply cable” (flat side faces DLT-V6210 connector panel). Tightening the nut hand-tight. © by DLoG GmbH DLT-V6210 Manual V1.00... -
Page 30: Securing The Power Supply Cable To The Strain Relief Rail
Tighten the mounting screws alternatingly. ATTENTION: Screw on sufficiently but make sure that the cable is not pinched or damaged. Fig. 8.6: Cable clip secured to the strain relief rail. Page 30 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 31: Connecting The Usb, Ethernet And Com Cables
Only use accessories that have been tested and approved by Advantech-DLoG for the respective DLT-V6210. DLT-V6210 may not be connected to the power supply if external devices are being connected/removed (not applicable for USB devices) Otherwise considerable damage could be caused to both DLT-V6210 and the peripheral devices. -
Page 32: Ethernet Cable
ATTENTION: Screw on sufficiently but make sure that the cable is not pinched or damaged. Fig. 8.8: Ethernet cable on the connector panel; secured to the strain relief rail Page 32 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 33: Com Cable
Closing off unused cable compartment openings Close off all unused cable compartment openings with the dummy grommet so that they are sealed. Fig. 8.10: Unused cable outlets sealed off with dummy grommet © by DLoG GmbH DLT-V6210 Manual V1.00 Page 33 / 61... -
Page 34: Attaching The Cable Cover
The device is not completely sealed due to incorrect attachment of the cables and the cable cover. The protection class/category of DLT-V6210 is only ensured if the cable cover is properly installed. Improper installation can result in liquid penetrating into DLT-V6210 during operation. -
Page 35: Automatic Shutdown - Functional Description
Please find fuse type details in section 8.4 Power cable, grounding The supply voltage is then linked to DLT-V6210’s ignition input via a switch, for example, the key switch of the ignition (also with a fuse). - Page 36 “WM_QUERYENDSESSION”, i.e. the backup data must be saved without user confirmation and within the preset time. Configuration „MDevice program” is used to configure the automatic shutdown function. The „MDevice manual” can be found online in the download center at www.advantech-dlog.com. Page 36 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH...
-
Page 37: Operation
Time between switching off and on: 10 seconds After DLT-V6210 is shut down and switched off, it needs to wait at least 10 seconds until the device can react to a switch-on signal (<Power> button / ignition). -
Page 38: Operating The Touchscreen (Pct)
Clean, dry, soft gloves − Suitable touch stylus Multi-touch capability Depending on the installed operating system type, the PCT touchscreen of DLT-V6210 is multi-touch capable. This means it can detect two touch points simultaneously. Page 38 / 61 DLT-V6210 Manual V1.00... -
Page 39: Front Keys And Leds
Blinking : 0.2 sec. on / 0.8 sec. off Temperature sensor faulty Ambient temperature lies beyond the Blinking : 0.5 sec. on / 0.5 sec. off permitted range © by DLoG GmbH DLT-V6210 Manual V1.00 Page 39 / 61... -
Page 40: External Connectors
1 A at 5 V. Depending on the connected devices, the maximum current consumption may be significantly lower. Using the MDevice tool, you can select whether +5 VDC or RI is output on pin 9 of COM1. Page 40 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 41: Usb
Depending on the cable layout and interference from the environment, it may be impossible to use the cable length of 100 m given in the specification (IEEE 802.3 standard). The recommendation in this context is to use a shorter cable. © by DLoG GmbH DLT-V6210 Manual V1.00 Page 41 / 61... -
Page 42: Cfast Slot Under The Antenna Cap
Only use CFast cards that have been approved by Advantech-DLoG. NOTICE: Physical damage Improper opening of the antenna cap can impair the function of entire DLT-V6210 system and in particular the Wi-Fi functionality. − The antenna cap may only remain open during the service work. -
Page 43: Integrated Power Supply Unit
Integrated power supply unit Integrated power supply unit DLT-V6210 is equipped with a galvanically separated, integrated DC power supply unit. Power is connected to the back of the unit using a Phoenix Contact plug. There is no power switch. Power supply... -
Page 44: Dc Voltage Supply Connection
Fig. 11.2: DC Power supply cable with Phoenix Combicon, 3-pin WARNING Electrical shock or fire due to incorrect power supply cable. Only use original Advantech-DLoG power supply cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. Page 44 / 61 DLT-V6210 Manual V1.00... -
Page 45: Fig. 11.3: Dc Connection Cable Pin Assignment
Integrated power supply unit Fig. 11.3: DC connection cable pin assignment © by DLoG GmbH DLT-V6210 Manual V1.00 Page 45 / 61... -
Page 46: Optional Equipment
Optional equipment Optional equipment NOTICE: Physical damage Please only use accessories that have been tested and approved by Advantech-DLoG for the respective DLT-V6210. 12.1. Integrated low profile Wi-Fi antenna (optional) Fig. 12.1: Integrated low profile Wi-Fi antenna (optional) Technical data Application Wi-Fi IEEE 802.11 a/b/g/n Dual Band Diversity... -
Page 47: External Wi-Fi Antenna, Remote (Optional)
100 mW / 20 dBm power 12.3. Wi-Fi card (optional) Technical data Wi-Fi PCIe MiniCard Integrated in the device at the factory by Advantech-DLoG (internal PCIe MiniCard slot). Driver Generally, only drivers for Wi-Fi cards approved by Advantech-DLoG can be integrated into operating system images. -
Page 48: Keyboards And Keyboard Mounts (Optional)
Optional equipment 12.4. Keyboards and keyboard mounts (optional) A USB keyboard can be connected to DLT-V6210. Advantech-DLoG offers the following keyboards and mountings: Fig. 12.3: SMALL keyboard − SMALL keyboard − Mountable − Protection class IP65 − Keyboard layouts: German, English, French Fig. -
Page 49: Scanner And Scanner Bracket (Optional)
Please contact your Advantech-DLoG sales representative if needed. Fig. 12.7: Touch stylus example 12.7. USB recovery stick (optional) The optional Advantech-DLoG recovery stick allows images to be backed up and restored onto DLT- V6210 when necessary (backup & recovery). Please contact your Advantech-DLoG sales representative if needed. -
Page 50: Maintenance
Check whether all connected cables are secured and the cable cover shuts tightly. WARNING Risk of accident due to unstable attachment of DLT-V6210. If the attachment of DLT-V6210 becomes loose and breaks during moving, this can lead to severe accidents. ... -
Page 51: Cleaning The Dlt-V6210
Do not use any abrasive glass cleaner or cloths that could scratch the touchscreen. Cleaning the housing Ensure that DLT-V6210 is switched off and currentless. Clean the housing with a slightly dampened cloth. Do not use compressed air, a high-pressure cleaner or vacuum cleaner, as this can damage the surface. -
Page 52: Malfunctions
You can use Reset to reset the software recalibration. Please contact DLoG GmbH if DLT-V6210 malfunctions. You can find the contact address in section Technical customer support. Page 52 / 61 DLT-V6210 Manual V1.00... -
Page 53: Reasonably Foreseeable Misuse
Reasonably foreseeable misuse Reasonably foreseeable misuse Observe the intended use The DLT-V6210 industrial PCs are data communication terminals for use in commercial environments (e.g. logistics, warehousing, manufacturing). The DLT-V6210 industrial PCs: − are not approved for use in EX zones (potential explosion hazard). -
Page 54: Guidelines And Certificates
16.1. EMC guideline 16.1.1. Shielded components All components connected to the DLT-V6210, as well as cable connections must meet the legal EMC requirements for compliance with the EMC legislation. Screened bus, LAN cables and connectors must be used. 16.1.2. EMC EU DLT-V6210 devices fulfill the requirements of the EU Directive "„2014/30/EU Elektromagnetische... -
Page 55: Fcc Usa/Can
(2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. © by DLoG GmbH DLT-V6210 Manual V1.00 Page 55 / 61... - Page 56 Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe B prescrites dans la norme sur le matérial brouilleur: “Appareils Numériques,” NMB-003 édictée par l’Industrie. FCC ID: M82-DLV6210 IC: 9404A-DLV6210 SW: V1.0 HW: V1.0 Page 56 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH...
-
Page 57: Red (Radio Equipment Directive) 2014/53/Eu
RED (Radio Equipment Directive) 2014/53/EU With regard to the RED (Radio Equipment Directive) 2014/53/EU the statements as below in the declaration of conformity for DLT-V6210 industrial PC to apply. Česky Toto zařízení je v souladu se základními požadavky a ostatními odpovídajícími ustanoveními Směrnice 2014/53/EU. -
Page 58: Ce Marking
In France, Wi-Fi operation outdoors is only permitted in the 2454 – 2483.5 MHz range at max. 10 mW EIRP. 16.4. CE marking The devices of DLT-V6210 series were tested and fulfill the CE conformity requirements and carry the CE mark on the rear side of the device. 16.5. Taiwan BSMI screen warning WARNING 使用過度恐傷害視力. -
Page 59: Technical Customer Support
Technical customer support Technical customer support Please contact your distributor, sales representative or Advantech-DLoG's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: − Product name − Serial number −... -
Page 60: Return Shipment Form
[ ] Unit was already damaged on delivery (please enclose a copy of the delivery note) [ ] Delivery was incomplete Missing parts: [ ] The following error occurs when operating the unit: [ ] Separate error report is enclosed Page 60 / 61 DLT-V6210 Manual V1.00 © by DLoG GmbH... -
Page 61: List Of Figures
List of figures List of figures Fig. 3.1: Dimensions of DLT-V6210 ............................ 12 Fig. 7.1: Position VESA drill holes of DLT-V6210 ........................ 21 Fig. 8.1: Cable compartment ............................... 25 Fig. 8.2: Cable sealing set ..............................25 Fig. 8.3: Example - 2 cables with cable grommets and 5 dummy grommets inserted ............26 Fig.
