- Page 1 User Manual DLT-V73A Series Industrial Computer...
-
Page 2: Manual Version
Manual version Manual version: V1.02 Completed on: July 23, 2024 Revision History: Version Date Manual modifications Description DLT-V73A Series V1.00 December 20, 2023 Models DLT-V7310AP, V7312AP und V7312AP+ Charging temperature battery pack changed Weight of the Devices updated V1.01 March 7, 2024... - Page 3 Note regarding all links and website content included in this document: Advantech Co., Ltd. is not responsible for the accessibility of the websites and for the content of external links contained in this document. The content and accessibility of the linked websites are the sole responsibility of their operators.
- Page 4 No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan, R.O.C. The importer: Advantech Europe B.V. Science Park Eindhoven 5708, 5692ER, Son en Breugel, The Netherlands Hereby, Advantech Co., Ltd. declares that the radio equipment type DLT-V7310AXXXXXXXXXXXX DLTV7310AXXXXXXXXXXXX DLT-V7312AXXXXXXXXXXXX DLTV7312AXXXXXXXXXXXX (X=0-9, A-Z, a-z, any character, “－”...
-
Page 5: Technical Customer Support
The exact wording of any error messages A complete description of the problem Find the contact data of our Global Advantech Service Centers on our website: https://erma.advantech.com You can find this return shipment form on page Advantech Europe B.V. Service & Support Email: helpdesk.munich@advantech.de... -
Page 6: Initial Inspection
Our dealers are well trained and ready to give you the support you need to get the most from your Advantech products. In fact, most problems reported are minor and can be easily solved over the phone. -
Page 7: Table Of Contents
5.3.3. DLT-V7312AP+ ........................37 5.3.4. VESA drill holes ........................37 5.4. Integrated power supply, power supply cable (optional) ..............38 5.4.1. DC voltage supply connection ....................40 5.4.2. DC Power supply cable ......................41 DLT-V73A Series User Manual V1.02 7 / 147... - Page 8 10.1. Safety notes ............................88 10.2. OS-specific configuration ........................89 10.3. Customer-specific WLAN profiles ......................89 11. WWAN Configuration ........ 90 11.1. Safety notes ............................91 11.2. Preparation work at the factory (delivery status) ................. 92 DLT-V73A Series User Manual V1.02 8 / 147...
- Page 9 15.3. Scanner and scanner bracket (optional) ................... 126 15.4. Touch stylus (optional) ........................127 15.5. Protective film for touchscreen (optional) ..................128 16. Repairs, Modifications ......129 16.1. Authorized Advantech Service Centers ..................... 130 DLT-V73A Series User Manual V1.02 9 / 147...
- Page 10 19.4. RoHS Directive EU ..........................140 19.5. RED (Radio Equipment Directive) 2014/53/EU ................. 141 19.6. CE marking ............................142 19.7. CNROHS ............................143 20. Return shipment form ......144 21. List of figures ........... 145 DLT-V73A Series User Manual V1.02 10 / 147...
-
Page 11: Introduction
Introduction DLT-V73A Series User Manual V1.02 11 / 147... -
Page 12: About The Dlt-V73A Manuals
User Manual Complete operating Skilled personnel PDF file at our websites instructions Startup Manual and User Manual apply to all models of the DLT-V73A Series: DLT-V7310AP (PCAP-Touch) DLT-V7312AP (PCAP-Touch) DLT-V7312AP+ (PCAP-Touch) DLT-V73A Series User Manual V1.02... -
Page 13: Further Available Manuals
Android 12 Skilled PDF file at our Software description and above personnel websites 1.1.3. Abbreviations used Term Abbreviation Lithium-ion battery pack Battery pack Operating System Projected-capacitive PCAP Uninterrupted Power Supply Liquid Crystal Display DLT-V73A Series User Manual V1.02 13 / 147... -
Page 14: Design Elements Used In The Manuals
Signal word CAUTION means that slight bodily injury can occur if this information is not observed. NOTICE Prevent system malfunction and property damage Information about possible property damage to avoid damaging hardware or losing data NOTE Notes provide optional additional information DLT-V73A Series User Manual V1.02 14 / 147... -
Page 15: Text Formatting Conventions
Text in italics, Please refer to manual section 1.1 manual chapters underlined Examples Program files In quotation File “quectel.exe“ … marks File names In directory “C:/Program Files” …. Directories Links Underlined, blue Website https://www.advantech.com DLT-V73A Series User Manual V1.02 15 / 147... -
Page 16: Safety Chapter
Safety Chapter Safety Chapter DLT-V73A Series User Manual V1.02 16 / 147... -
Page 17: Please Read And Observe
Safety Chapter 2.1. Please read and observe These safety instructions apply to all device models in the DLT-V73A Series: For DLT-V7310AP, DLT-V7312AP and DLT-V7312AP+ in various equipment levels. WARNING Non-observance of the safety instructions can result in injury to persons and in physical damage, e.g., due to incorrect commissioning procedures or due to maintenance work not being completed. -
Page 18: Battery Pack Safety
This liquid must not under any circumstances be permitted to come into contact with eyes, skin or clothing. On contact with eyes or skin, rinse immediately with clear, running water and consult a doctor. DLT-V73A Series User Manual V1.02 18 / 147... - Page 19 DLT-V73A, the warranty for this device will be rendered void. 2. The battery packs must be certified for the DLT-V73A. 3. Do not use battery packs from any other Advantech devices; they are not compatible. Prevent physical damage due to deep discharge.
-
Page 20: Hf Radiation
Any modifications to the DLT-V73A radio equipment which are not expressly approved by the party responsible for the compliance can lead to the withdrawal of the operating license for this device. DLT-V73A Series User Manual V1.02 20 / 147... -
Page 21: Information On Safe Mounting
2. During the mounting process, observe the requirements of the vehicle manufacturer relating to attaching auxiliary devices and connecting auxiliary consumers. 3. Observe all requirements relating to welding or drilling on support components of the vehicle. DLT-V73A Series User Manual V1.02 21 / 147... -
Page 22: Information On Safe Electrical Installation
2. Do not open or modify the DLT-V73A. 3. Only connect or disconnect electrical connections when the device is in a de-energized state. 4. Use only original Advantech power supply cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. -
Page 23: Safety During Ongoing Work Operations
The DLT-V73A must be disconnected from the vehicle battery while the vehicle battery is being charged or it must be ensured that the maximum permitted input voltage of the DLT-V73A is not exceeded. DLT-V73A Series User Manual V1.02 23 / 147... -
Page 24: Regular Maintenance Work
Accessories and peripherals Accessories and peripherals may only be installed or integrated if expressly approved by Advantech for the respective DLT-V73A. If other parts are attached or installed and connected, claims for warranty and / or product liability will be lost. -
Page 25: Recycling Information
They must be disposed of properly in accordance with local regulations. Please contact the responsible authorities in your country/region to find out about the applicable regulations for proper disposal, if necessary. DLT-V73A Series User Manual V1.02 25 / 147... -
Page 26: Functional Description
Functional Description Functional Description DLT-V73A Series User Manual V1.02 26 / 147... -
Page 27: Intended Use
Only use accessories that have been tested and certified for the respective DLT-V73A. Requirements for safe operation Proper transport and storage Proper setup and use Proper maintenance and service Operation by trained personnel DLT-V73A Series User Manual V1.02 27 / 147... -
Page 28: Mount, Operate And Service The Device Correctly
Do not damage the name plate or remove it from the device. Information on the labels on the device (examples): Model name Serial number FCC ID (Radio) Barcode (for Advantech-internal use only) DLT-V73A Series User Manual V1.02 28 / 147... -
Page 29: Unpacking, Storing
Unpacking, Storing Unpacking, Storing DLT-V73A Series User Manual V1.02 29 / 147... -
Page 30: Packing List
2. Never use the antenna as a handle. It can break due to the weight involved. 3. Do not hold the DLT-V73A by the strain relief rail. 4. Use the assistance of a second person for installation work. DLT-V73A Series User Manual V1.02 30 / 147... -
Page 31: Storage
3. Place devices front-to-front in this case. The VESA mounting point on the rear side of the device can damage the touchscreen of another device. 4. Use protective material (non-flammable!) between the devices as a precaution. DLT-V73A Series User Manual V1.02 31 / 147... -
Page 32: Technical Data - Device
Technical Data – Device Technical Data – Device DLT-V73A Series User Manual V1.02 32 / 147... -
Page 33: General
10.4" XGA color TFT 1024 x 768 resolution 500 cd/m² brightness DLT-V7312AP 12.1" XGA color TFT 1024 x 768 resolution 600 cd/m² brightness DLT-V7312AP+ 12.1" XGA color TFT 1024 x 768 resolution 600 cd/m² brightness DLT-V73A Series User Manual V1.02 33 / 147... - Page 34 Technical Data – Device The LCD of the DLT-V73A series fulfills the highest quality standards and was inspected for pixel defects. However, due to technological reasons pixel defects can occur. This is not a malfunction; it is a part of the technical specifications.
-
Page 35: Environmental Conditions
Class 5M3 according to EN 60721-3-5 and shock resistance US Highway Truck according to MIL-STD 810F IP protection class IP66 NOTE If the CPU temperature rises to 85 °C, the CPU is throttled to avoid overheating. DLT-V73A Series User Manual V1.02 35 / 147... -
Page 36: Device Dimensions
Technical Data – Device 5.3. Device dimensions 5.3.1. DLT-V7310AP Fig. 5-1: Dimensions DLT-V7310AP (in mm) 5.3.2. DLT-V7312AP Fig. 5-2: Dimensions DLT-V7312AP (in mm) DLT-V73A Series User Manual V1.02 36 / 147... -
Page 37: Dlt-V7312Ap
100 x 100 mm. It can be used to attach VESA-compatible mountings to mount the DLT- V73A at the deployment location. Depth of thread: M6 x 6mm Please observe the mounting information in manual chapter: 13.2.4 VESA mounting hole pattern DLT-V73A Series User Manual V1.02 37 / 147... -
Page 38: Integrated Power Supply, Power Supply Cable (Optional)
Connection to SELV circuit only. The SELV circuit is a secondary circuit that is designed and protected so that its voltages will not exceed a safe value both when operating correctly or if a single error occurs. DLT-V73A Series User Manual V1.02 38 / 147... - Page 39 The fuse of the power supply unit is located inside the device and is not accessible from outside. The power supply is equipped with a 16 AT fuse. In case of problems please contact our helpdesk. DLT-V73A Series User Manual V1.02 39 / 147...
-
Page 40: Dc Voltage Supply Connection
“Ignition on” means that a control signal can be routed to this connection (e.g., ignition of a vehicle), that matches the supply voltage level and is able to supply at least 1 W to the DLT-V73A. The signal reference is DC-. DLT-V73A Series User Manual V1.02 40 / 147... -
Page 41: Dc Power Supply Cable
Technical Data – Device 5.4.2. DC Power supply cable Fig. 5-6: DC connection cable assignment DLT-V73A Series User Manual V1.02 41 / 147... -
Page 42: Technical Data - Radio
Technical Data – Radio Technical Data – Radio DLT-V73A Series User Manual V1.02 42 / 147... -
Page 43: Identification Of Radio Equipment Variants
For products that operate in the frequency band 5.150 to 5.350 GHz, wireless access systems (WAS), including radio local area networks (RLANs), shall be restricted to indoor use. Wireless modulation BPSK/QPSK/16QAM/64QAM/256QAM/1024QAM/DBPSK/DQPSK/CCKGFSKπ/4- DQPSK,8DPSK DLT-V73A Series User Manual V1.02 43 / 147... - Page 44 5755 - 5795 | 40 MHz(HB) 10 ± 1.0 dbm WiFi 5 5 GHz WiFi 802.11ac 5755 - 5795 | 40 MHz(HB) 10 ± 1.0 dbm WiFi 5 5 GHz WiFi 802.11ac 5775 | 160 MHz(HB) DLT-V73A Series User Manual V1.02 44 / 147...
-
Page 45: Radio Cards (Optional)
LTE Cat 4 (EM05) and LTE Cat 6 (EM06) and both GNSS FCC ID: XMR201906EM06A (China excluded) FCCID Maximum transmitting Class 3 (23dBm±2dB) for LTE FDD power Class 3 (23dBm±2dB) for LTE TDD Class 3 (24dBm+1/-3dB) for WCDMA DLT-V73A Series User Manual V1.02 45 / 147... -
Page 46: Antennas (Optional)
5 GHz<2.98 dBi WLAN external <4.0 dBi Permanent Mount External Antenna 1399.17.0040 WWAN external <5.3 dBi Permanent Mount External Antenna TLS.01.305111 GPS external 30 +- 4,5 dBi Permanent Mount External Antenna 1750001782 DLT-V73A Series User Manual V1.02 46 / 147... -
Page 47: Wlan Antenna
Number of antennas Available color Blue Type Omnidirectional antenna Antenna gain Max. 4.44 dBi (without loss through the cable) Impedance 50 Ω Polarization Vertical/horizontal Maximum transmitting power 100 mW / 20 dBm DLT-V73A Series User Manual V1.02 47 / 147... -
Page 48: External Wlan Antenna Ieee 802.11 A/B/G/N
Connector labeling N-type or TNC N, Jack, female, bottom RSMA plug for RSMA socket on the terminal Scope of delivery 3 m antenna cable Maximum transmitting power 100 mW / 20 dBm DLT-V73A Series User Manual V1.02 48 / 147... -
Page 49: External Wwan Antenna 2G, 3G, 4G
Impedance 50 Ω Polarization Vertical Dimensions Height 79.45 mm Diameter 42 mm Cable length IP protection IP67 and IP69K Compatible WWAN card: (see section 6.2.1 Radio card for WWAN: QUECTEL EM06- A/E) DLT-V73A Series User Manual V1.02 49 / 147... -
Page 50: External Gps Antenna
N-Type or TNC N, Jack, female, bottom SMA (M) plug for SMA socket on terminal Scope of delivery 5 m antenna cable Compatible WLAN card: (see section 6.2.1 Radio card for WWAN: QUECTEL EM06-A/E) DLT-V73A Series User Manual V1.02 50 / 147... -
Page 51: Bluetooth Integrated
Technical Data – Radio 6.3.5. Bluetooth integrated Bluetooth 2.1+EDR/3.0/4.1 LE/4.2 BLE/ BT 5.0 DLT-V73A Series User Manual V1.02 51 / 147... -
Page 52: Connectors
Connectors Connectors DLT-V73A Series User Manual V1.02 52 / 147... -
Page 53: Connectors Under The Cable Cover
Connectors 7.1. Connectors under the cable cover Cable cover Connectors located on the connector panel under the cable cover: Fig. 7-1: Connectors on the connector panel under the cable cover DLT-V73A Series User Manual V1.02 53 / 147... - Page 54 COM2 as RS-485 Half Duplex (USB to serial) CAN BUS Digital I/O (see chapter 7.1.1 AddOn Module) 1 x RSMA External WLAN antenna 2 x SMA (optional) External WWAN antenna External GPS antenna Power supply 12/24/48 VDC nominal DLT-V73A Series User Manual V1.02 54 / 147...
-
Page 55: Fig. 7-2: Rj45 Network Ports
100 m given in the specification (IEEE 802.3 standard). The solution here is the use of a shorter cable. DLT-V73A Series User Manual V1.02 55 / 147... -
Page 56: Fig. 7-3: Pin Assignment Com1 - Rs-232
WLAN external antenna incl. 3 m cable WWAN antenna WWAN external Antenna incl. 3 m cable GPS antenna GPS external antenna incl. 3 m cable Fig. 7-4: Pin assignment description external antennas DLT-V73A Series User Manual V1.02 56 / 147... -
Page 57: Addon Module
This adapter is accessible via the underside of the device and features a RJ45 socket. The RJ45 connection port has two integrated status LEDs and are assigned as follows: Fig. 7-5: LAN interface Fig. 7-6: AddOn RJ45 network ports DLT-V73A Series User Manual V1.02 57 / 147... -
Page 58: Fig. 7-7: Addon Usb-A 3.2 Gen1 Interface
Connectors 7.1.1.2. USB-A 3.2 Gen1 Fig. 7-7: AddOn USB-A 3.2 Gen1 interface NOTE The USB-A 3.2 Gen1 connection is mounted horizontal in the AddOn Module. DLT-V73A Series User Manual V1.02 58 / 147... -
Page 59: Fig. 7-8: Addon Com2 Interface
+-15 kV IEC-61000-4-2 air gap, +-8 kV IEC-61000-4-2 contact and +-15 kV Human Body Model (HBM). Fig. 7-8: AddOn COM2 interface Pin assignment (suggested DB9 connector pinout): Fig. 7-9: AddOn Pin assignment COM2 DLT-V73A Series User Manual V1.02 59 / 147... -
Page 60: Fig. 7-10: Addon Com2 Interface
Human Body Model (HBM). Fig. 7-10: AddOn COM2 interface Pin assignment (suggested DB9 connector pinout): Fig. 7-11: AddOn Pin assignment COM2 Termination default settings for RS-485/422 Full Duplex is Off. NOTE DLT-V73A Series User Manual V1.02 60 / 147... -
Page 61: Fig. 7-12: Addon Com2 Interface
Human Body Model (HBM). Fig. 7-12: AddOn COM2 interface Pin assignment (suggested DB9 connector pinout): Fig. 7-13: AddOn Pin assignment COM2 Termination default settings for RS-485 Half Duplex is Off. NOTE DLT-V73A Series User Manual V1.02 61 / 147... - Page 62 E connection, may significantly degrade signal quality and effectively stop the data flow. In challenging environments, electrically-isolated connections (via the RS-422/485 option) or external converter from RS-232-E according to RS-422/485 are strongly recommended. DLT-V73A Series User Manual V1.02 62 / 147...
-
Page 63: Fig. 7-14: Addon Can Fd Interface
A 120 Ω termination resistor is not integrated in the add-on module, so it may have to be added externally. The API description and a test application can be found on the Advantech download page at www.advantech.com. Fig. 7-14: AddOn CAN FD interface... -
Page 64: Fig. 7-16: Y-Cable
If both CAN channels are to be used, the following Y-cable (PN: 1700035114-01) may have to be used to adapt both CAN channels to the "standard" CAN DSUB 9 pinning. Fig. 7-16: Y-cable DLT-V73A Series User Manual V1.02 64 / 147... -
Page 65: Fig. 7-17: Addon Digital I/O Interface
The Digital I/O interface is galvanically separated from the overall system. A matching driver is integrated in the operating system. An API description as well as sample application are available upon request. Contact your Advantech sales representative if necessary. Fig. 7-17: AddOn Digital I/O interface... -
Page 66: Opening The Cable Cover
5. The device is only permitted to be operated again once the cable cover is properly sealed again; only then is the protection class guaranteed. Closing the cable cover Please refer to section 14.3.7 Attach the cable cover . DLT-V73A Series User Manual V1.02 66 / 147... -
Page 67: Connectors Under The Antenna Cap / Wlan Diversity Antenna
USB Type-C USB 3.2 Gen1 interface SIM-Tray Mini-SIM-Card Slot Battery pocket Secured under the antenna cap Service USB SD-Card Slot Battery pocket Type-C USB3.2 SIM-Tray Fig. 7-19: Connectors located under the antenna cap DLT-V73A Series User Manual V1.02 67 / 147... -
Page 68: Open/Close The Wlan Antenna Cap Ieee 802.11 A/B/G/N/Ac
7. Use only SD-cards that have been approved for the product by Advantech. 8. The device is only permitted to be operated again once the antenna cap is properly sealed again; only then is the protection class guaranteed. DLT-V73A Series User Manual V1.02 68 / 147... -
Page 69: Fig. 7-21: Wlan Antenna Cap Ieee 802.11 A/B/G/N/Ac
Fig. 7-21: WLAN antenna cap IEEE 802.11 a/b/g/n/ac 1. Unfasten the three screws on the antenna with a Torx screwdriver, Tx20. 2. Remove the antenna cap from the device. Result: Fig. 7-22: WLAN antenna cap IEEE 802.11 a/b/g/n/ac opened DLT-V73A Series User Manual V1.02 69 / 147... -
Page 70: Fig. 7-23: Connected Adapter To Usb Type-C Service Port
Optional USB Type-C to Type A adapter can now be connected to the Service Port. Fig. 7-23: Connected adapter to USB Type-C Service Port Closing the antenna cap: 1. Place the antenna cap back onto the DLT-V73A. 2. Tighten all screws alternatingly (1,0 Nm torque). DLT-V73A Series User Manual V1.02 70 / 147... -
Page 71: Operating The Dlt-V73A
Operating the DLT-V73A Operating the DLT-V73A DLT-V73A Series User Manual V1.02 71 / 147... -
Page 72: Safety Notes
Prevent system malfunction and property damage 1. While the vehicle battery is charging, disconnect the DLT-V73A from the vehicle battery. 2. Alternatively, ensure that the maximum permitted input voltage of the DLT-V73A is not exceeded. DLT-V73A Series User Manual V1.02 72 / 147... -
Page 73: Switching The Dlt-V73A On/Off
Devices with integrated UPS will switch automatically to UPS/battery power supply when the supply voltage is broken. 3. Or: Deactivate the ignition of the connected vehicle (depends on the automatic shutdown settings). DLT-V73A Series User Manual V1.02 73 / 147... - Page 74 Take care of the antenna cables. Do not pull, bend or squeeze the cables. Please also refer to chapter 15.1.3 Replacing the battery pack. 5. Open the battery cover. 6. Disconnect the battery pack. DLT-V73A Series User Manual V1.02 74 / 147...
-
Page 75: Operating The Touchscreen
Depending on the installed operating system, the PCAP touchscreen of the DLT-V73A is multi-touch capable. This means it detects simultaneously up to ten fingers in non- glove mode / two fingers in glove-mode / and one finger in thick-glove mode. DLT-V73A Series User Manual V1.02 75 / 147... -
Page 76: Operation Elements
− 100 x 100 mm spacing Pressure compensation element: Do not modify or remove Cable cover Drilled holes M6 for − Mounting brackets and − Accessory holders (On the left and right of the device respectively) DLT-V73A Series User Manual V1.02 76 / 147... -
Page 77: Front Side Dlt-V7310A And Dlt-V7312A
− S7 to S12 − Flash access − Power supply Note on the backlighting function on/off: The DLT-V73A will continue to react to keyboard, mouse and touchscreen inputs even if the backlight is switched off. DLT-V73A Series User Manual V1.02 77 / 147... -
Page 78: Front Side Dlt-V7312Ap
− Suitable touch stylus (capacitive peak) NFC Reader LED: Flash access Front keys: − Display darker − Device on/off − Display brighter LED: Temperature: Red blinking = over- or undertemperature in the device DLT-V73A Series User Manual V1.02 78 / 147... -
Page 79: Operating States (Leds)
-30 and +64 °C again. Computer start-up/normal operational state/shutdown delay time FLASHING Ambient temperature value is outside the permitted range, i.e., < -30 °C or > +50 °C DLT-V73A Series User Manual V1.02 79 / 147... -
Page 80: Operating The Dlt-V73A With Ups
3. Do not allow water or other liquids to come into contact with the device (exercise particular caution with corrosive liquids). 4. Do not allow it to come into contact with fire. For details about the UPS, see section 15.1 Integrated UPS (optional). DLT-V73A Series User Manual V1.02 80 / 147... -
Page 81: Internal Speaker, Sound
− 100 x 100 mm spacing Pressure compensation element: Do not modify or remove Cable cover Drilled holes M6 for − Mounting brackets and − Accessory holders (On the left and right of the device respectively) DLT-V73A Series User Manual V1.02 81 / 147... -
Page 82: General Device Configuration
General Device Configuration General Device Configuration DLT-V73A Series User Manual V1.02 82 / 147... -
Page 83: Operating Systems (Optional)
Battery pack charge settings (only on devices with optional UPS) Operation with gloves possible (only on devices with PCAP touchscreen) NOTE The Android Software Manual is available at our websites. DLT-V73A Series User Manual V1.02 83 / 147... -
Page 84: Energy Options And Battery Pack Durability
All DLT-V73A devices with Android have had the power options set at the factory so that the optimal duration of the battery pack can be achieved. Do not modify or deactivate the power options. DLT-V73A Series User Manual V1.02 84 / 147... -
Page 85: Automatic Shut Down
Once the shut-off delay (after run time) has elapsed, the operating system will shut down and the device will automatically shut down (e.g., after one minute or a signal from the operating system). DLT-V73A Series User Manual V1.02 85 / 147... -
Page 86: Mtouch
• Android 12 GMS; • For more details about the required installation and the handling of the MTouch application, please refer to the separately available Android Software Manual from our homepage. www.advantech.com DLT-V73A Series User Manual V1.02 86 / 147... -
Page 87: Wlan Configuration
WLAN Configuration 10. WLAN Configuration DLT-V73A Series User Manual V1.02 87 / 147... -
Page 88: Safety Notes
2. Observe all applicable regulations for your deployment location/country with regard to operating channels, radio frequencies and the maximum permissible transmitting power. Examples of country-specific regulations: Region Radio approval RED (formerly R&TTE) China SRRC Canada Canada IC DLT-V73A Series User Manual V1.02 88 / 147... -
Page 89: Os-Specific Configuration
WLAN configuration description DLT-V73A with Android In the following manual sections 10.3. Customer-specific WLAN profiles To create a customer-specific profile: 1. Use the configuration program that is already factory-installed on the DLT-V73A (Android). DLT-V73A Series User Manual V1.02 89 / 147... -
Page 90: Wwan Configuration
WWAN Configuration 11. WWAN Configuration DLT-V73A Series User Manual V1.02 90 / 147... -
Page 91: Safety Notes
2. Observe all applicable regulations for your deployment location/country with regard to operating channels, radio frequencies and the maximum permissible transmitting power. Examples of country-specific regulations Region Radio approval RED (formerly R&TTE) DLT-V73A Series User Manual V1.02 91 / 147... -
Page 92: Preparation Work At The Factory (Delivery Status)
Prevent system malfunction and property damage Radio cards are located inside the devices and are not accessible from the outside. Only the manufacturer and its authorized service centers may open the device and install/remove radio cards. DLT-V73A Series User Manual V1.02 92 / 147... -
Page 93: Sim Card For Wwan (Customer-Specific) And M2M Sim
Inserting the SIM card: DLT-V73A must be switched off! NOTE If the SIM card contains a PIN, the customer must set up an application for the PIN query. For this reason, we recommend not using a PIN. DLT-V73A Series User Manual V1.02 93 / 147... -
Page 94: Configuration Of Radio Card Quectel Em05/Em06
USA: QUECTEL EM06-A Europe / Korea: QUECTEL EM06-E China: QUECTEL EM05-CE The WWAN configuration is identical for both radio cards. For this reason, the abbreviation QUECTEL EM05/EM06 is used. DLT-V73A Series User Manual V1.02 94 / 147... -
Page 95: Nfc Near Field Communication
NFC Near Field Communication 12. NFC Near Field Communication DLT-V73A Series User Manual V1.02 95 / 147... -
Page 96: Technology
Calling up web links if a URL in the corresponding format has been stored in the NFC chip Can be used with active devices as an access key at terminals to content and for services DLT-V73A Series User Manual V1.02 96 / 147... -
Page 97: Mechanical Installation
Mechanical Installation 13. Mechanical Installation DLT-V73A Series User Manual V1.02 97 / 147... -
Page 98: Safety Notes
6. Close off all unused cable openings of the rubber seal using the accompanying blind plugs so that they are sealed. 7. Close the DLT-V73A with the cable cover. 8. Install the DLT-V73A on the device mounting. DLT-V73A Series User Manual V1.02 98 / 147... -
Page 99: Mounting The Dlt-V73A At The Deployment Location
Never install the system in a closed environment where the cooling air is unable to dissipate accumulated heat to the outside. The maximum permissible ambient temperature for the entire system needs to be taken into account for the specific application area. DLT-V73A Series User Manual V1.02 99 / 147... -
Page 100: Electrically Isolated Dlt-V73A Mounting
(e.g., motor supply) or that are otherwise burdened by consumers. Connecting the DLT-V73A to large electrical loads, such as converters for the forklift motor may result in random restarts, malfunctions and/or irreparable damage to the device. DLT-V73A Series User Manual V1.02 100 / 147... -
Page 101: Attaching Accessories To The Dlt-V73A
Only use mounting brackets, accessories and mounting materials that have been tested and approved for the respective DLT-V73A. All mounting brackets, accessories and mounting materials supplied by Advantech are only intended to be used for attachment of the Advantech Industrial Computers and the peripheral devices and may not be misused. DANGER Risk of accident during vehicle operation if the mounting of the DLT-V73A becomes loose and breaks while driving. -
Page 102: Vesa Mounting Hole Pattern
Screw-in depth VESA mounting hole pattern: M6 x 6 mm Suitable mounting material: Cylinder-head screws int.hex DIN912 M6 Washers ISO 8738 (DIN 1440)-A6-A2 Fig. 13-1: VESA mounting hole pattern on the rear side of the DLT-V73A DLT-V73A Series User Manual V1.02 102 / 147... -
Page 103: Attach The Mounting Bracket
The DLT-V73A housing has holes provided for attaching a mounting bracket. Fig. 13-2: DLT-V73A with mounting bracket When a mounting bracket from a DLT-V72 is already present, an adapter plate is required to screw on the mounting bracket Fig. 13-3: Adapter plate DLT-V73A Series User Manual V1.02 103 / 147... -
Page 104: Fig. 13-4: Mounting Bracket With Adapter On Dlt-V73A
2. Mount the Mounting bracket on the adapter plate Fig. 13-4: Mounting bracket with adapter on DLT-V73A Screw-in depth: M6 x 6 mm Suitable mounting material: Cylinder head screws DIN912 M6 Washers DIN 125 - A 6.4 DLT-V73A Series User Manual V1.02 104 / 147... -
Page 105: Attach Accessories
Screw-in depth: M6 x 6 mm Suitable mounting material: Cylinder head screw DIN 912 M6 Washer ISO 8738 - A6-A2 Please note: In addition to a mounting bracket, no other accessory holder can be attached. DLT-V73A Series User Manual V1.02 105 / 147... -
Page 106: Electrical Installation
Electrical Installation 14. Electrical Installation DLT-V73A Series User Manual V1.02 106 / 147... -
Page 107: Safety Notes
6. Important: If a DLT-V73A with integrated UPS is installed in a vehicle, the EMERGENCY-OFF switch of the vehicle has no effect on the DLT-V73A. This also applies to the peripherals supplied by the device. DLT-V73A Series User Manual V1.02 107 / 147... -
Page 108: Power Cables And Fuses
WARNING Electric shock, fire due to incorrect cable routing or insufficient grounding. 1. Use only original Advantech power cables; these meet the specific requirements for low-temperature flexibility, UV resistance, oil resistance, etc. 2. Make sure that the power supply cables are run without kinks and are protected (securely protected against crushing and abrading). -
Page 109: Observe The Potential Ratios
DLT-V73A (e.g., printers), be sure to power up the peripheral devices at the same time or after the DLT-V73A; otherwise, you may encounter start-up problems, malfunctions or even irreparable damage to the device. DLT-V73A Series User Manual V1.02 109 / 147... -
Page 110: Preparations
11 x Zylinderkopfschrauben DIN 912 M3x12 zum Befestigen der Kabel an der Zugentlastungsschiene 9 x Kabelschelle zum Befestigen der Kabel an der Zugentlastungsschiene Rubber seal with blind plugs : Fig. 14-2: DLT-V73A cable sealing set DLT-V73A Series User Manual V1.02 110 / 147... -
Page 111: Fig. 14-3: Dlt-V73A Cable Cover With Screws
Tools Allen wrench, size 2.5mm, 3mm and 5mm Philips screwdriver, size 1 Flat head screwdriver, size 0 Torx screwdriver, Tx20 Socket wrench, size 7mm Torque wrench DLT-V73A Series User Manual V1.02 111 / 147... -
Page 112: Procedure
1. Place the rubber seal in the sealing surface of the cable compartment (see figure). 2. Press the plugs of the rubber seal into the holes of the frame. Fig. 14-4: Rubber seal inserted in the cable compartment DLT-V73A Series User Manual V1.02 112 / 147... -
Page 113: Ensure A Proper Electrical Connection
DLT-V73A connector panel. (flat side facing down) Fig. 14-7: Ring tongue on the ground bolt 3. Lastly, fit the nut and fasten it. (Torque 1.0 Nm) Fig. 14-8: Fasten nut DLT-V73A Series User Manual V1.02 113 / 147... -
Page 114: Plugging In And Screwing On The Power Supply Cable
14.3.3. Plugging in and screwing on the power supply cable Mounting screws 1. Plug the DC power supply cable into the DC slot. 2. Tighten the mounting screws hand-tight. Fig. 14-9: Tighten power supply cable DLT-V73A Series User Manual V1.02 114 / 147... -
Page 115: Secure The Power Supply Cable To The Strain Relief Rail
Otherwise, the cables may break or the insulation may be damaged. Make sure that the power supply cables are run without kinks and are mechanically protected, securely protected against crushing and abrading. DLT-V73A Series User Manual V1.02 115 / 147... -
Page 116: Connecting The Usb, Ethernet And Com Cables
DLT-V73A cannot take place. 5. Only power up the DLT-V73A when all devices have been connected and the DLT-V73A has been closed correctly (remember the cable cover!). Otherwise, you may damage the DLT-V73A. DLT-V73A Series User Manual V1.02 116 / 147... -
Page 117: Close Off Unused Cable Openings
To prevent fluids or dust penetrating the DLT-V73A during ongoing operation, the cable compartment on the device must be sealed using the corresponding cable cover. The protection class is only ensured if the cable cover is properly installed. DLT-V73A Series User Manual V1.02 117 / 147... -
Page 118: Pressure Compensation Element
Prevent system malfunction and property damage Do not modify or remove the pressure compensation element; doing so would make the device leak and the IP protection would no longer be ensured. Fig. 14-15: Pressure compensation element DLT-V73A Series User Manual V1.02 118 / 147... -
Page 119: Optional Equipment
Optional Equipment 15. Optional Equipment DLT-V73A Series User Manual V1.02 119 / 147... -
Page 120: Integrated Ups (Optional)
Usually <2h from 0% 100% maximal 3h (depends on temperature) Charging temperature 0 to 40 °C Storage temperature -20 to +50 °C Maximum output power 50 W Battery voltage 7,2 V Battery capacity 3250 mAh DLT-V73A Series User Manual V1.02 120 / 147... -
Page 121: Charging The Battery Pack
6. Do not continue to use the DLT-V73A if you notice an unusual level of heat or an unusual smell during charging. 7. Provide for sufficient ventilation of the DLT-V73A during charging. DLT-V73A Series User Manual V1.02 121 / 147... -
Page 122: Replacing The Battery Pack
1. Use only original Advantech battery packs. 2. The battery packs must be authorized/approved for the DLT-V73A. 3. Do not use battery packs from any other Advantech devices; they are not compatible. 4. If battery packs from other manufacturers are inserted in the DLT-V73A, the warranty provided by Advantech for this device will be rendered void. -
Page 123: Fig. 15-3: Wlan Diversity Antenna
Fig. 15-4: Opened WLAN Diversity Antenna 4. Loosen the battery cover by removing the fastening screws and removing the battery cover. Fig. 15-5: Screws from the battery cover Fig. 15-6: Opened battery compartment DLT-V73A Series User Manual V1.02 123 / 147... -
Page 124: Fig. 15-7: Inserted Battery Pack
Make sure that the removal tab of the battery pack is under the battery cover. Fig. 15-8: Removal tab under the battery cover 4. Mount the WLAN diversity antenna (torque 1.0 Nm) 5. Fasten the antenna cap again as specified (torque 1.0 Nm) DLT-V73A Series User Manual V1.02 124 / 147... -
Page 125: Keyboards And Keyboard Mounts (Optional)
Protection class IP66 Keyboard layouts: US, German Fig. 15-9: Full keyboard Small keyboard SIK21 Protection class IP66 21 Keyboard Fig. 15-10: 21-Key keypad Fig. 15-11: Keyboard mounting example DLT-V73A Series User Manual V1.02 125 / 147... -
Page 126: Scanner And Scanner Bracket (Optional)
You can connect scanners to either the USB interface or the serial interface. If connected to COM1, the scanner can be powered through the interface with a voltage of 5V or 12V. Use only scanners that have been approved by Advantech. Optional scanner brackets are available for the DLT-V73A. -
Page 127: Touch Stylus (Optional)
Optional Equipment 15.4. Touch stylus (optional) Advantech offers some touch stylus pens (with associated mountings) for resistive and PCAP touchscreens. Use only touch stylus that have been approved by Advantech. NOTE The Accessory catalog is available at our websites. Touch stylus with mounting... -
Page 128: Protective Film For Touchscreen (Optional)
The adhesive side of the film must be facing downwards! 7. Carefully press on the foil. 8. Then using a wiper (wooden wiper) to push out any air bubbles to the corners. DLT-V73A Series User Manual V1.02 128 / 147... -
Page 129: Repairs, Modifications
Repairs, Modifications 16. Repairs, Modifications DLT-V73A Series User Manual V1.02 129 / 147... -
Page 130: Authorized Advantech Service Centers
Accessories and peripherals Accessories and peripherals may only be installed or integrated if expressly approved by Advantech for the respective DLT-V73A. If other parts are attached or installed and connected, claims for warranty and / or product liability will be lost. -
Page 131: Maintenance
Maintenance 17. Maintenance DLT-V73A Series User Manual V1.02 131 / 147... -
Page 132: Regular Maintenance Work
Risk of accident due to unstable attachment of DLT-V73A If the attachment of DLT-V73A becomes loose and breaks during moving, this can lead to severe accidents. Perform checks for the attachment as described above at regular intervals. DLT-V73A Series User Manual V1.02 132 / 147... -
Page 133: Replacing The Battery Pack
Maintenance 17.2. Replacing the battery pack See manual section 15.1 Integrated UPS (optional) . 17.3. Replacing the touchscreen protective film See manual section 15.5 Protective film for touchscreen (optional) DLT-V73A Series User Manual V1.02 133 / 147... -
Page 134: Troubleshooting
Troubleshooting 18. Troubleshooting DLT-V73A Series User Manual V1.02 134 / 147... - Page 135 Operating system Operating system or image damaged must be reinstalled No WLAN connection Connection deactivated Activate connection in the Control Panel AP access problem List ACL and check access rights to AP DLT-V73A Series User Manual V1.02 135 / 147...
- Page 136 No network connection Connection deactivated Activate connection in the Control Panel Invalid network settings Check network and protocol settings Network problems Check status LEDs on RJ45 connection socket, plug connection and cable DLT-V73A Series User Manual V1.02 136 / 147...
-
Page 137: Guidelines And Certificates
Guidelines and Certificates 19. Guidelines and Certificates DLT-V73A Series User Manual V1.02 137 / 147... -
Page 138: Simplified Eu Declaration Of Conformity
No.1, Alley 20, Lane 26, Rueiguang Road, Neihu District, Taipei 114, Taiwan, R.O.C. The importer: Advantech Europe B.V. Science Park Eindhoven 5708, 5692ER, Son en Breugel, The Netherlands Hereby, Advantech Co., Ltd. declares that the radio equipment type DLT-V7310AXXXXXXXXXXXX DLTV7310AXXXXXXXXXXXX DLT-V7312AXXXXXXXXXXXX DLTV7312AXXXXXXXXXXXX (X=0-9, A-Z, a-z, any character, “－”... -
Page 139: Usa/Canada: Fcc Part 15 Statement
Any change or modification which is not expressly approved in the corresponding pages can lead to the withdrawal of the operating license for this device. FCC ID Please find the FCC ID on the device labels. DLT-V73A Series User Manual V1.02 139 / 147... -
Page 140: Ices Canada
We hereby confirm the conformity of our products compliant with the RoHS Directive 2011/65/EU of the European Parliament and Council of June 8, 2011 on the restriction of the use of hazardous substances in electrical and electronic equipment. DLT-V73A Series User Manual V1.02 140 / 147... -
Page 141: Red (Radio Equipment Directive) 2014/53/Eu
Guidelines and Certificates 19.5. RED (Radio Equipment Directive) 2014/53/EU With regard to the RED (Radio Equipment Directive) 2014/53/EU the statements in the declaration of conformity for the DLT-V73A Industrial Computer apply. DLT-V73A Series User Manual V1.02 141 / 147... -
Page 142: Ce Marking
Guidelines and Certificates 19.6. CE marking The devices of the DLT-V73A series were tested and fulfill the CE conformity requirements and carry the CE mark on the rear side of the device. DLT-V73A Series User Manual V1.02 142 / 147... -
Page 143: Cnrohs
Guidelines and Certificates 19.7. CNROHS DLT-V73A Series User Manual V1.02 143 / 147... -
Page 144: Return Shipment Form
[ ] Delivery was incomplete Missing parts: [ ] The following error occurs when operating the unit: [ ] Separate error report is enclosed Advantech Europe B.V. Service & Support Email: helpdesk.munich@advantech.de Phone: +49 (0)89 / 41 11 91 999 DLT-V73A Series User Manual V1.02... -
Page 145: List Of Figures
List of figures 21. List of figures DLT-V73A Series User Manual V1.02 145 / 147... - Page 146 Fig. 14-3: DLT-V73A cable cover with screws ............111 Fig. 14-4: Rubber seal inserted in the cable compartment ........112 Fig. 14-5: Toothed washer with nut ................113 Fig. 14-6: Toothed washer ..................113 DLT-V73A Series User Manual V1.02 146 / 147...
- Page 147 Fig. 15-9: Full keyboard .................... 125 Fig. 15-10: 21-Key keypad ..................125 Fig. 15-11: Keyboard mounting example ..............125 Fig. 15-12: Example scanner bracket ................ 126 Fig. 15-13: Examples touch stylus ................127 DLT-V73A Series User Manual V1.02 147 / 147...
Need help?
Do you have a question about the DLT-V73A Series and is the answer not in the manual?
Questions and answers
