Read more about this in manual chapter 13.1.3 Observe the potential ratios.

12.2.3. Attaching accessories to the DLT-V72

Only use mounting brackets, accessories and mounting materials that have been tested
and approved for the respective DLT-V72.
All mounting brackets, accessories and mounting materials supplied by Advantech are
only intended to be used for attachment of the Advantech Industrial Computers and the
peripheral devices and may not be misused.
DANGER
DLT-V72 Series User Manual V2.70
5. If you want to connect devices fed by other power sources to
the DLT-V72, such as certain Wedges, printers and so on, be
sure to power up the peripheral devices at the same time or
after the vehicle-mount. Otherwise, you may encounter start-up
problems, malfunctions or even irreparable damage to the
device.
Risk of accident during vehicle operation if the mounting of
the DLT-V72 becomes loose and breaks while driving.
Ensure the following when attaching the mounting on the VESA
mounting hole pattern:
1. Special mechanical knowledge is required for correct
mounting!
2. Use suitable mounting material.
3. Use suitable screws: Screws that are too long can penetrate
the back of the DLT-V72 and cause irreparable damage.
Screws that are too short do not provide secure mounting.
4. Use suitable washers.
5. Observe the maximum screw-in depth of the hole of the
mounting hole pattern: The recommended screw-in depth of
Dx1 always applies (screw diameter x 1).
6. If you ordered a bracket from Advantech, it includes the suitable
screws and washers. Please use them.
130 / 173
Mechanical Installation
