Summary of Contents for Advantech UBX-110
- Page 1 User Manual UBX-110 8K UHD Fanless Mini Box PC...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
- Page 4 Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –...
- Page 5 UBX-110H-BI700 UBX-110, i7 1185G7E, barebone UBX-110H-UCL00 UBX-110H-UCL00 UBX-110, Celeron® 6305E, barebone, MIT UBX-110H-UI300 UBX-110H-UI300 UBX-110, i3 1115G4E, barebone, MIT UBX-110H-UI500 UBX-110H-UI500 UBX-110, i5 1145G7E, barebone, MIT UBX-110H-UI700 UBX-110H-UI700 UBX-110, i7 1185G7E, barebone, MIT UBX-MKV01 UBX-110 VESA mounting kit with thermal isolation UBX-110 User Manual...
- Page 6 70 dB (A). The equipment should only be installed in a restricted access area. DISCLAIMER: These instructions are provided according to IEC 704-1 stan- dards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. UBX-110 User Manual...
- Page 7 FSP/ FSP060-DAAN2) suitable for use at TMA 60 °C (140 °F) min., and the out- put is rated 12 V , 5.0A min., ES1. If you need further assistance, contact Advantech for additional information. Consignes de Sécurité Veuillez lire attentivement ces instructions de sécurité.
- Page 8 L'équipement ne doit être installé que dans une zone d'accès restreint. AVERTISSEMENT: Cet ensemble d'instructions est donné conformément à la norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclarations contenues dans ce. Ce modèle est destiné à être alimenté par une alimentation certifiée UL (adapta- teur: FSP/FSP060-DAAN2), adaptée à...
-
Page 9: Table Of Contents
2.1.1 Warning Message ................. 6 UBX-110 I/O Connectors ................6 Figure 2.1 UBX-110 Front View........... 6 Figure 2.2 UBX-110 Rear View ........... 6 Hardware Installation ................7 2.3.1 Memory, M.2 SSD, and Wi-Fi Module Installation ......7 VESA Mounting Kit Installation ............... 10 Figure 2.3 UBX-110 Horizontal Installation........ - Page 10 UBX-110 User Manual...
-
Page 11: Chapter 1 General Information
Chapter General Information... -
Page 12: Introduction
The UBX-110 is fanless and supports DDR4 memory and M.2 2280 SATA SSD. It has a 0 ~ 40 °C operating temperature. The UBX-110 dimensions (W x D x H) are 182.5 x 141 x 35 mm. It has a compact body with multiple I/Os including 1 x RS232, 2 x LAN, 6 x USB 3.0 ports, and it supports 2 x M.2 2280 and 1 x M.2 2230 expansion... -
Page 13: Mechanical Specifications
1.3 Mechanical Specifications 1.3.1 System Dimensions 1.3.2 Weight 0.94 kg UBX-110 User Manual... -
Page 14: Power Requirements
Lithium: 3V/220 mAh 1.5 Environmental Specifications 1.5.1 Temperature Operating Temperature: 0 ~ 40 °C (If the UBX-110 operating temperature is up to 45 °C, please use a power adapter with a temperature spec that is compli- ant.) Storage Temperature: -20 ~ 60 °C ... -
Page 15: Chapter 2 Hardware Installation
Chapter Hardware Installation... -
Page 16: Introduction
Wi-Fi module installation. 2.1.1 Warning Message In working mode, the UBX-110 is capable of operation at an ambient temperature of up to 40 °C. In such cases, the temperature of the top cover may reach a high value. -
Page 17: Hardware Installation
2.3 Hardware Installation 2.3.1 Memory, M.2 SSD, and Wi-Fi Module Installation Please follow these steps to install the memory and M.2 SSD for the UBX-110. Remove the specified 6 screws. After removing the 6 screws, please remove the bottom cover. You will see one DDR4 memory slot, two SSD slots, and one Wi-Fi module slot under the shield- ing cases, respectively. - Page 18 Please use a tool to help remove the shielding case without breaking it. a) In the memory slot, please add the DDR4 memory and stick the thermal pads inside and on top of the shielding case. UBX-110 User Manual...
- Page 19 UBX-110 User Manual...
-
Page 20: Vesa Mounting Kit Installation
2.4 VESA Mounting Kit Installation The UBX-110 VESA mounting kit is compatible with horizontal installation and verti- cal installation. Users can select an appropriate installation. Figure 2.3 UBX-110 Horizontal Installation Figure 2.4 UBX-110 Vertical Installation... - Page 21 Please follow these steps to install the UBX-110 VESA mounting kit with thermal iso- lation. Please remove the four footpads from the bottom cover of the UBX-110. After removing the foot pads, put the UBX-110 in the thermal isolation bracket (P/N: 1960109659N001).
- Page 22 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. ©Advantech Co., Ltd. 2023...
