Installing the MAPD

In this Chapter

This chapter divides topics into two basic categories, planning-oriented tasks, and
installation-oriented tasks.
NOTE:
Use this topic table as a checklist for carrying out the tasks described in
Chapter 2.
Topic
"Planning: Task 1 — Planning the Installation"
"Planning: Task 2 — Determining the Location for the MAPD in the Switch"
"Planning: Task 3 — Familiarizing Yourself with the MAPD System Assembly"
"Installation: Task 1 — Gathering the Required Tools"
"Installation: Task 2 — Reviewing the Safety Guidelines"
"Installation: Task 3 — Installing the MAPD Assembly in the Switch"
"Planning: Task 4 — Connecting to the LAN"
"Planning: Task 5 — Evaluating the Terminal Requirements (Optional)"
"Installation: Task 4a — Installing a Terminal Using a Direct Connection to a
DC Switch"
"Installation: Task 4b — Installing a Terminal Using a Direct Connection to a
DC Switch"
"Installation: Task 4c — Install a Terminal Using Modem Connections"
"Installation: Task 5 — Connect the Maintenance Modem"
"Installation: Task 6 — Finalize and Test the Hardware"
2-2 Issue 3 May 2002
