Setting up the MAPD Configuration
g. In the MIM Support: field, type n
h. In the CRV Length: field, type 2
i. In the Event Minimization: field accept the default value n
For all other fields, accept the default values (some fields may be on page
2 of the STATION screen).

MAPD Administration

MAPD administration tasks are performed by Avaya. The objective of these tasks
is to establish connectivity to the customer's network, and, ultimately, to register
the customer's system with Avaya Technical Support Center (TSC). Other
pre-administration tasks (logging in) and post-administration tasks (backing up the
system), are covered in this section also.
MAPD Task 1: Setting the MAPD Clock (mandatory for all installations)
MAPD Task 2: Assigning the MAPD Machine ID (optional)
MAPD Task 3: Rebooting the MAPD
MAPD Task 4: Testing MAPD/LAN connectivity (optional)
MAPD Task 5: Registering and Backing up the system
Task 1: Basic Administration —
Logging in to the MAPD System
All of the MAPD administrative tasks (Task 1 through Task 7) require you to log in
to the MAPD system from the MAPD administrative terminal (which can be either
a remote terminal or a terminal located in the switch room).
This task is an orientation task. The objective of this task is to log in to the MAPD
system and get to the Main Menu. Before you start the procedure to log in, refer to
Appendix B for terminal and modem settings. You will need this information to
complete Step 3.
