Installing the MAPD
Planning: Task 4 — Connecting to the
LAN
The MAPD Board cable has four connectors available for outside connections:
RJ45 Local Area Network (LAN)
Admin/Port B, RS-232 (Local administration port)
Maint/Port A, RS-232 (Remote Maintenance Port)
DCIU, RS-232 (Reserved for future use)
Figure 2-12. MAPD Board Cable Connections
2-22
Issue 3 May 2002
Switch
MAPD
Cable
MAPD
Board
Maint/Port A (RS-232 F)
Admin/Port B (RS-232 F)
RJ45 to LAN
DCIU (Reserved for future use)
