Setting up the MAPD Configuration
Task 7: Performing a Backup of the
Removable Medium
The Removable medium refers to the SanDisk PCMCIA FlashDisk, which is part
of the MAPD system order. (See Appendix C,
The SanDisk PCMCIA FlashDisk should already have been inserted as described
in Step 3 of
(Chapter 2).
1. At the front panel of the MAPD, make sure the SanDisk PCMCIA FlashDisk
is inserted in the slot for the PCMCIA disk.
2. The Avaya service technician assists the TSC in performing a backup of
the system.
NOTE:
Recall that the craft login has been deactivated at this point.
3. The TSC accesses the screen, "Removable Media Operations" in Chapter
3, and performs Save Configuration Data to Removable Media.
4. When the backup has completed, the field technician labels and dates this
disk as the backup disk.
3-20 Issue 3 May 2002
"Installation: Task 3 — Installing the MAPD Assembly in the Switch"
''Ordering Information.'')
