Cv/Lan Utilities - Avaya DEFINITY Manual

CVLAN and DLG System Administration

CV/LAN Utilities

1. ASAI Test
2. ASAI Trace
3. ISDN Trace
4. ISDN Alarm
5. Exit
This line is used to provide abbreviated help on the currently selected field.
EXIT REFRESH
Screen 4-40. CV/LAN Utilities
NOTE:
This screen will appear only if CV/LAN is also installed.
Menu Item
ASAI Test
ASAI Trace
ISDN Trace
ISDN Alarm
Exit
To use this menu, select the number of the task you wish to perform. (Press the
number, or press
number, and press
4-66 Issue 3 May 2002
Maintenance

CV/LAN Utilities

ENTER
Description
Tests communication with the DEFINITY system for each
node ID using ASAI heartbeats.
Decodes an ASAI message stream.
Traces messages through the kernel protocol stack.
Used in debugging.
Activates or deactivates ASAI maintenance alarming on
the DEFINITY system.
Returns you to preceding menu.
or use the arrow keys to move the cursor to the desired
TAB
.)
ENTER
HELP
