Task 5A, Alternative Procedures
The MAPD sends 20 packet messages to itself, listens for responses, and
issues a series of messages similar to the following.
The messages which follow are the result of your last request.
At the <EOF> : prompt press return to continue.
64 bytes from 192.168.25.10: icmp_seq*0,
64 bytes from 192.168.25.10: icmp_seq*1,
64 bytes from 192.168.25.10: icmp_seq*2,
64 bytes from 192.168.25.10: icmp_seq*3,
64 bytes from 192.168.25.10: icmp_seq*4,
64 bytes from 192.168.25.10: icmp_seq*5,
64 bytes from 192.168.25.10: icmp_seq*6,
64 bytes from 192.168.25.10: icmp_seq*7,
64 bytes from 192.168.25.10: icmp_seq*8,
64 bytes from 192.168.25.10: icmp_seq*9,
----192.168.25.10 PING statistics----
20 packets submitted, 20 packets received. 0 percent packet loss
round-trip (ms) min/avg/max =x/x/x
<EOF>:
Screen 3-8. Results of Pinging the MAPD
11. Based on the
the test results that are displayed at the bottom of the screen. For example.
Guidelines for Evaluating
an Internal MAPD Ping
The results displayed in the packet loss field (z) will be either 0 percent or 100
percent. Recall that this test is internal to the MAPD system, and does not access
the customer's LAN.
If the test reports 0 percent packet loss, the test was successful. Continue
with the next step in this procedure.
If the test reports 100 percent packet loss, the test failed. If it failed, verify
that you did use the correct address for the MAPD system assembly. If you
did, then contact your remote maintenance center. After the problem has
been resolved, repeat the test and then continue with the following steps.
"Guidelines for Evaluating an Internal MAPD
----(address) PING statistics----
x packets submitted, y packets received. z percent
packet loss
round-trip (ms) min/avg/max =aa/bb/cc
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
time=0. xx
Issue 3 May 2002
Ping", examine
3-15
