CVLAN and DLG System Administration

CV/LAN Administration

This line is used to provide abbreviated help on the currently selected field.
CANCEL REFRESH
Screen 4-19. CV/LAN Administration
NOTE:
This screen will appear only if CV/LAN is also installed.
Field Name
Node ID
Port
Heartbeat State
Number of Clients
4-38 Issue 3 May 2002

CV/LAN Administration

Node ID Port Heartbeat State
signal01 __
signal02 __
signal03 __
signal04 __
signal05 __
signal06 __
signal07 __
signal08 __
Description
Read-only. Node ID used by CV/LAN clients.
Port number used on the DEFINITY system. Valid range
is 1 to 12. Each port can only be assigned once.
The state of the ASAI heartbeat sever for this node ID.
Either ASAI on or off.
The number of clients administered to use this node ID.
Number of Clients
____ ____
____ ____
____ ____
____ ____
____ ____
____ ____
____ ____
____ ____
HELP STATE CLIENT PORT
