Installation: Task 5 — Connect the Maintenance Modem
Installation: Task 5 — Connect
the Maintenance Modem
For this task, make sure you have the correct ED1E434-11G311 cable (in a length
between 5 and 50 feet). Refer to
complete this task.
Switch
MAPD
Board MAPD
External
Cable
Figure 2-17. Connecting the Maintenance Modem
1. Physically connect one end of the cable to the modem and the other end to
the MAPD maintenance port (Maint/Port A).
2. Set the modem options as per
and if necessary, connect the modem to a phone jack and power on.
Figure 2-17
RJ45 to LAN
DCE CONNECTION
Group 311 Cable
RS232
ADMIN/PORT B
DTE CONNECTION
Group 311 Cable
Group 311
Cable
Maint/Port A
DCIU (Reserved for future use)
(ignore the shaded areas) as you
Tip/
Ring
RS232
Modem
Modem
H600-258-1
Null Modem
Modem
DCE port on 715 BCT
Modem*
Avaya Remote Access
*
! CAUTION:
Modem must be nongrounded
(that is, the modem must be
isolated from the ground).
"Modem Option Settings"
Issue 3 May 2002
