CVLAN and DLG System Administration
CV/LAN Port Status/Control —
Message Collection Period
This line is used to provide abbreviated help on the currently selected field.
CANCEL REFRESH
Screen 4-48. Message Collection Period
NOTE:
This screen will appear only if CV/LAN is also installed.
This screen enables you to set the message collection period for a port. When this
screen is first displayed, a port number (1 to 12) replaces yy in the port field.
The port number comes from the previous screen (whichever port the cursor was
on).
After you enter a value for Period on this screen and press
screen reappears with the cursor positioned at the beginning of the new entry.
Changing the collection period clears the traffic counts (messages to the
DEFINITY system and messages from the DEFINITY system) on the CV/LAN
Port Status/Control screen.
Field Name
Node ID
Port
Period
4-80 Issue 3 May 2002
CV/LAN Port Status/Control
Message Collection Period
Node ID: signalXX
Period: ____
ENTER CLEAR
Description
Read-only. Node ID number used by CV/LAN clients.
The port for which messages are to be collected.
Display-only.
The time period (in minutes) during which messages are
to be collected. Range = 1-720. Default = 30.
Port: yy
HELP
ENTER
the previous
