Installing the MAPD
Installation: Task 3 — Installing the
MAPD Assembly in the Switch
This section describes the tasks needed to install the MAPD system hardware
and peripheral hardware. The MAPD system installation tasks are the same for
all switch types. These tasks include:
Task 1: Install the MAPD system assembly
Before beginning these tasks, refer to the following worksheets:
—
—
—
Appendix B, "Terminal and Modem Option Settings"
"Worksheet B-1: Terminals/Modems"
Task 2: Connect to the LAN
Task 3: Install the terminal (optional)
Task 4: Connect the Maintenance modem
Task 5: Finalize and test the hardware

Precautions

You must follow this precautionary guideline for all installation scenarios.
!
WARNING:
To prevent damage to the MAPD system assembly, make sure that you (or
the factory, for new switches) have connected the system assembly adapter
cable to the port connector on the back of the switch (as described in Task 5,
Step 2,
before you insert the system assembly in the switch carrier.
You can install the system assembly in the switch when the switch is
powered on or off. When the assembly is inserted in the slots of the switch
carrier, it will automatically power up, run diagnostics, and boot. To avoid a
disk crash, never remove the assembly without first completing the
shutdown procedure to shut down the MAPD system (and allowing the disk
to completely spin down). For the same reason, do not cycle the power on
the switch (for example, during switch acceptance tests) once the system
assembly is inserted unless you have first shut down the MAPD system.
Refer to the
shutdown procedure.
2-14 Issue 3 May 2002
"Worksheet A-1: Port Slot Assignments (Before Carrier
Arrangement)"
"Worksheet A-2: Port Assignments (for Carrier Rearrangement)"
"Worksheet A-3: Port Slot Locations for the MAPD System
Assembly"
"Installation: Task 3 — Installing the MAPD Assembly in the
"Reset System (DLG and CV/LAN)"
Switch")
section in Chapter 4 for the
