Installing the MAPD
Installation: Task 4c — Install
a Terminal Using Modem Connections
This task describes how to connect a terminal via a modem to Admin/Port B of the
MAPD. Refer to
perform this task. To make sure the modems that you are installing are on the list
of supported peripherals, see Appendix B,
NOTE:
This task can also be used for remote connection to the Maint/Port A.
Switch
MAPD
Board MAPD
External
Cable
Figure 2-16. Connecting a terminal to the MAPD via Modem
2-32 Issue 3 May 2002
Figure 2-16 (ignore the shaded area of the figure), while you
RJ45 to LAN
DCE CONNECTION
Group 311 Cable
RS232
ADMIN/PORT B
DTE CONNECTION
Group 311 Cable
Group 311
Cable
Maint/Port A
DCIU (Reserved for future use)
''Worksheet B-1:
Tip/
Ring
RS232
Modem
Modem
H600-258-1
Null Modem
Modem
DCE port on 715 BCT
Modem*
Avaya Remote Access
*
! CAUTION:
Modem must be nongrounded
(that is, the modem must be
isolated from the ground).
Terminals/Modems.''
Dial-up
Terminal
Optional
Printer
Dial-up
Terminal
Tip/
Ring
