Wiring Power Distribution
and Other Modules

1734-PDN Communication Interface Module

NC
CHAS GND
C
V
NC = No Connection
CHAS GND = Chassis Ground
C = Common
V = Supply

1734-PDN Module Wiring Diagram

0
NC
2
CHAS
GND
4
C
12/24V dc
V dc
Power
6
V
NC = No Connection
CHAS GND = Chassis Ground
C = CommonV = Supply
DeviceNet Power
NC
CHAS GND
C
V
1
NC
3
CHAS
GND
5
This supply will be
C
connected to the internal
field power bus.
7
V
Publication 1734-UM001D-EN-P - April 2008
Install POINT I/O Modules
DeviceNet Connector
System Power
41970
63
