88 Install POINTBlock I/O Modules
Publication 1734-UM001D-EN-P - April 2008
1734D-IA8XOW8 POINTBlock 8 ac In/8 Relay Out Modules
Inputs
0 4
1 5
2 6
10-60
3 7
0-9
1's Node Address Rotary Switch
10's Node Address Rotary Switch
1734D-IA8XOW8 POINTBlock 8 ac In/8 Relay Out Modules Wiring
Diagram
120V ac
Field Power
Inputs
Power
0 1 0 1
NC NC 0 1
2 3 2 3
NC NC 2 3
4 5 4 5
L2in L2in L2 L2
V ac
6 7 6 7
L1in L1in L1 L1
RTB 0 RTB 1
This supply will be connected to the internal power bus.
NC = No connection
L2/N = AC Return/Neutral
L1 = AC Power
Module Status
Network Status
Outputs
0 4
I/O status
1 5
2 6
3 7
42004
Outputs
0 1 0 1 0 1
4 5 0A 1A 4A 5A
2 3 2 3 2 3
6 7 0B 1B 4B 5B
4 5 4 5 4 5
L2 L2 2A 3A 6A 7A
6 7 6 7 6 7
L1 L1 2B 3B 6B 7B
RTB 2 RTB 3 RTB 4
41976
