POINT I/O Protected Sink Output Module
Catalog Numbers 1734-OV2E, 1734-OV4E, and 1734-OV8E
Series C
Inside . . .
For
Installation Instructions
See Page
2
3
4
5
6
7
8
11
12
14
18
21
23
Publication
1734-IN585C-EN-E - December 2005

Advertisement

Table of Contents
loading

Summary of Contents for Rockwell Automation C Series

  • Page 1: Table Of Contents

    Installation Instructions POINT I/O Protected Sink Output Module Catalog Numbers 1734-OV2E, 1734-OV4E, and 1734-OV8E Series C Inside . . . See Page Important User Information Prevent Electrostatic Discharge Environment and Enclosure North American Hazardous Location Approval About the Module Install the Mounting Base Install the Module Install the Removable Terminal Block (RTB) Remove a Mounting Base...
  • Page 2: Important User Information

    In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
  • Page 3: Prevent Electrostatic Discharge

    POINT I/O Protected Sink Output Module 3 Prevent Electrostatic Discharge This equipment is sensitive to electrostatic discharge, ATTENTION which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. •...
  • Page 4: Environment And Enclosure

    4 POINT I/O Protected Sink Output Module Environment and Enclosure This equipment is intended for use in a Pollution Degree ATTENTION 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 meters without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
  • Page 5: North American Hazardous Location Approval

    POINT I/O Protected Sink Output Module 5 North American Hazardous Location Approval The following information applies when Informations sur l’utilisation de cet équipement operating this equipment in hazardous en environnements dangereux: locations: Products marked “CL I, DIV 2, GP A, B, C, D” are suitable Les produits marqués “CL I, DIV 2, GP A, B, C, D”...
  • Page 6: About The Module

    6 POINT I/O Protected Sink Output Module About the Module Use this series C module with the following: • ControlNet adapters with RSLogix 5000 software, version 11 or higher • DeviceNet adapters • EtherNet/IP adapters with RSLogix 5000 software, version 11 or higher •...
  • Page 7: Install The Mounting Base

    POINT I/O Protected Sink Output Module 7 Install the Mounting Base To install the mounting base on the DIN rail, proceed as follows. POINT I/O is grounded through the DIN rail to chassis ATTENTION ground. Use zinc-plated yellow-chromate steel DIN rail to assure proper grounding.
  • Page 8: Install The Module

    8 POINT I/O Protected Sink Output Module Install the Module When you insert or remove the module while backplane ATTENTION power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.
  • Page 9 POINT I/O Protected Sink Output Module 9 To install the module on the DIN rail, proceed as follows. 1. Use a bladed screwdriver to rotate the keyswitch on the mounting base clockwise until the number required for the type of module being installed aligns with the notch in the base.
  • Page 10 10 POINT I/O Protected Sink Output Module 3. Insert the module straight down into the mounting base. 44012 4. Press to secure. The module locks into place. 30880 Publication 1734-IN585C-EN-E - December 2005...
  • Page 11: Install The Removable Terminal Block (Rtb)

    POINT I/O Protected Sink Output Module 11 Install the Removable Terminal Block (RTB) A removable terminal block comes with your wiring base. To remove, pull up on the RTB handle. Remove or replace the mounting base without removing any of the wiring. When you connect or disconnect the removable terminal WARNING block (RTB) with field-side power applied, an electrical...
  • Page 12: Remove A Mounting Base

    12 POINT I/O Protected Sink Output Module Remove a Mounting Base To remove a module from the DIN rail, remove any installed module and the module installed in the base to the right. Remove the removable terminal block, if wired. 1.
  • Page 13 POINT I/O Protected Sink Output Module 13 4. Pull on the I/O module to remove from the base. When you insert or remove the module while backplane ATTENTION power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.
  • Page 14: Wire The Module

    14 POINT I/O Protected Sink Output Module Wire the Module Refer to the figures to wire the module. If you connect or disconnect wiring while the field-side WARNING power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.
  • Page 15 POINT I/O Protected Sink Output Module 15 1734-OV2E Out 1 Out 0 Load Load V = 12/24V dc, C = Common 42014 Field power is supplied from internal power bus. Output Power Common Terminal Terminal Channel 0 Channel 1 Module power is supplied from the internal power bus. Publication 1734-IN585C-EN-E - December 2005...
  • Page 16 16 POINT I/O Protected Sink Output Module 1734-OV4E Out 0 Out 1 Out 2 Out 3 Load Load Load Load V = 12/24V dc, C = Common 42015 Field power is supplied from internal power bus. Output Power Common Terminal Terminal Channel 0 Channel 1...
  • Page 17 POINT I/O Protected Sink Output Module 17 1734-OV8E Load Load Out 0 Out 1 Load Load Out 3 Out 2 Load Load Out 4 Out 5 Out 7 Load Out 6 Load Common must be daisychained from a 1734 adapter, 1734-FPD, 1734-EP24DC, or from a user-supplied external terminal block.
  • Page 18: Configure The Module

    18 POINT I/O Protected Sink Output Module Example of Wiring for the 1734-OV8E Output Module Module Module Status Status Network Network Status Status DeviceNet 1734- 1734- OV8E The 1734-OV8E maximum load is 1 A min per channel, and 3 A total per module. System Power DeviceNet...
  • Page 19 POINT I/O Protected Sink Output Module 19 Default Data Map for the 1734-OV2E Output Module Message size: 1 Byte Produces Not used Ch1 Ch0 Channel status (scanner Rx) Where: 0 = no error, 1 = error Message size: 1 Byte Consumes Not used Ch1 Ch0 Channel state...
  • Page 20 20 POINT I/O Protected Sink Output Module Default Data Map for the 1734-OV8E Output Module Message size: 1 Byte Produces Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel (scanner Rx) status Where: 0 = no error, 1 = error Message size: 1 Byte Consumes Ch6 Ch5 Ch4 Ch3 Ch2 Ch1 Ch0 Channel...
  • Page 21: Troubleshoot The Module

    POINT I/O Protected Sink Output Module 21 Troubleshoot the Module 1734-OV8E 1734-OV2E 1734-OV4E Module Status Module Module Module Status Status Status Network Network Network Status Status Status Network Status NODE: NODE: NODE: 24VDC 24VDC 24VDC Sink Sink Sink Output Output Output Status of Output 0 &...
  • Page 22 22 POINT I/O Protected Sink Output Module Indication Probable Cause Recommended Action Network Status Device is not online. Apply power to the device, - Device has not completed wait for MAC-id to dup_MAC_id test. complete, and correct, if - Device not powered - check module needed.
  • Page 23: Specifications

    POINT I/O Protected Sink Output Module 23 Specifications 1734-OV2E/C, 1734-OV4E/C, and 1734-OV8E/C Protected Sink Output Modules Specification Value Number of Outputs 1734-OV2E - 2 (1 group of 2) non-isolated, sinking 1734-OV4E - 4 (1 group of 4) non-isolated, sinking 1734-OV8E - 8 (1 group of 8) non-isolated, sinking ON-State Voltage Range 10V dc min 24V dc nom...
  • Page 24 24 POINT I/O Protected Sink Output Module 1734-OV2E/C, 1734-OV4E/C, and 1734-OV8E/C Protected Sink Output Modules Specification Value Module Location 1734-TB or 1734-TBS wiring base assembly POINTBus Current 75 mA max @ 5V dc Power Dissipation 1734-OV2E - 0.8 W max @ 28.8V dc 1734-OV4E - 1.2 W max @ 28.8V dc 1734-OV8E - 2.0 W max @ 28.8V dc Thermal Dissipation...
  • Page 25 POINT I/O Protected Sink Output Module 25 1734-OV2E/C, 1734-OV4E/C, and 1734-OV8E/C Protected Sink Output Modules Specification Value Pilot Duty Rating 24V dc 1.0 A North American Temperature Code Field Wiring Terminations 1734-OV2E 0 - Output 0 1 - Output 1 2 - Output 0 3 - Output 1 4 - Common...
  • Page 26 26 POINT I/O Protected Sink Output Module Environmental Specifications Specification Value Operational IEC 60068-2-1 (Test Ad, Operating Cold), Temperature IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock) -20...55 °C (-4...131 °F) Storage Temperature IEC60068-2-1 (Test Ab, Unpackaged Non-operating Cold) IEC60068-2-2 (Test Bb, Unpackaged Non-operating Dry Heat) IEC60068-2-14 (Test Na, Unpackaged Non-operating Thermal Shock)
  • Page 27 See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other certification details. POINT I/O and POINTBus are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Publication 1734-IN585C-EN-E - December 2005...
  • Page 28 Outside United States Please contact your local Rockwell Automation representative for return procedure. Publication 1734-IN585C-EN-E - December 2005 PN 957974-57 Supersedes Publication 1734-IN585B-EN-P - March 2002 Copyright © 2005 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
