Removal and Installation Procedures

Preparation
RTX100A ISDB-T RF Signal Generator Service Manual
This subsection contains procedures for removal and installation of all mechani-
cal and electrical modules.
WARNING. Before performing this or any other procedure in this manual, read
the Safety Summary found at the beginning of this manual. Also, to prevent
possible injury to service personnel or damage to the RTX100A's components,
read Installation in Section 2, and Preventing ESD in this section.
This subsection contains the following items:
H Preparatory information that you need to properly perform the procedures
that follow.
H List of tools required to remove and disassemble all modules.
H Three module locator diagrams for finding the External modules (see Figure
5-2 on page 5-11), Board modules (see Figure 5-3 on page 5-12), and
Internal modules (see Figure 5-4 on page 5-13).
H Procedures for removal and reinstallation of the electrical and mechanical
modules.
H A disassembly procedure for removal of all the major modules from the
RTX100A at one time and for reassembly of those modules into the
RTX100A. Such a complete disassembly is normally only done when
completely cleaning the RTX100A. (Instructions for doing the actual
cleaning are found under Inspection and Cleaning at the beginning of this
section.)
WARNING. Before performing any procedure in this subsection, disconnect the
power cord from the line voltage source. Failure to do so could cause serious
injury or death.
