RTX100A ISDB-T RF Signal Generator Service Manual
c. Use a screwdriver with a T-10 Torx tip to remove the two screws
securing the RFI filter to the chassis.
d. Pull the RFI filter away from the chassis.
4. Reinstallation: Perform step 3 in reverse order to reinstall the RFI filter.
To J110 on the A40
AC Distributer board

Figure 5-15: RFI filter removal

Removal and Installation Procedures
RFI filter
5-33
