Adjustment Procedures

Requirement for Adjustment

Warm-up Period
Equipment Required

Table 4-1: Equipment required

Item
Spectrum analyzer
50 Ω SMA cable
50 Ω N(Fe)-to-75 Ω N(Fe) adapter
50 Ω N(Ma)-to-SMA(Fe) adapter
75 Ω BNC(Ma)-to-NC(Fe) adapter
RTX100A ISDB-T RF Signal Generator Service Manual
This section contains information needed to adjust the RTX100A.
The only adjustment in the RTX100A is for the carrier leakage.
Before proceeding, note the following requirement:
The RTX100A requires a 20 minute warm-up time in a +20 to +30 environment
before it is adjusted. Adjustment done before the operating temperature has
stabilized may cause errors in performance.
In addition, the spectrum analyzer requires appropriate warm-up time to meet the
specification.
Table 4-1 lists the test equipment required to adjust the carrier leakage. The table
identifies examples of recommended equipment and lists the required precision
where applicable. If you substitute other test equipment for the examples listed,
the equipment must meet or exceed the listed tolerances.
Qty. Minimum requirements
1 Resolution bandwidth: 10 Hz
1
1 Bandwidth: 2 GHz or higher
2
1
Recommended equipment
Agilent Technologies E4402B-COM
Candox Systems 5B-010-19-19-1000
Agilent Technologies 11852B
Stack Electronics BA057
Stack Electronics BA045
