Figure 8-5: Dvd Drive Unit - Tektronix RTX100A Service Manual

Replaceable Parts List
Replaceable parts list
Fig. &
Tektronix part Serial no.
index
number effective
number
8- - 5- - 1 119- - 7123- - 00
- - 2 671- - 5980- - XX
- - 3 211- - 0373- - 00
- - 4 211- - A269- - 00
- - 5 407- - 5049- - 00
1
5

Figure 8-5: DVD drive unit

8-12
Serial no.
discont'd Qty Name & description
1 DISK DRIVE;OPTICAL,CD- - RW/DVD- - R/RW DVD+R/RW,16.7
MB/SEC,650MEG/8.5GIG,IDE/ATAPI;TEAC MODEL
DV- - W28E- - 793
1 CIRCUIT BD ASSY:A50 DISK I/F,389- - 3739- - 00 WIRED
1 SCREW,MACHINE:4- - 40X0.25,PNH,STL ZN- - CM1,T10 TORX
4 SCREW,MACHINE:M2X4MM L,PNHSTL ZN- - C,CROSS
REC,W/FLAT (6MM OD) WASHER
1 BRACKET:DVD DRIVE,MTX100A,AL
RTX100A ISDB-T RF Signal Generator Service Manual
Mfr.
code
80009
80009
80009
80009
80009
A50
2
3
4
Mfr. part number
