Table 1-5: Certifications and compliances (Cont.)
Category
Safety
Installation (Overvoltage) Category
Overvoltage Category
Pollution Degree
Pollution Degree
IEC Characteristics
RTX100A ISDB-T RF Signal Generator Service Manual
Standards or description
Complies with the following safety standards/regulations:
UL 61010-1
CAN/CSA C22.2 No.61010-1-04
EN 61010-1:2001
Terminals on this product may have different installation (overvoltage) category designations. The
installation categories are:
CAT III Distribution-level mains (usually permanently connected). Equipment at this level is
typically in a fixed industrial location.
CAT II Local-level mains (wall sockets). Equipment at this level includes appliances,
portable tools, and similar products. Equipment is usually cord-connected.
CAT I Secondary (signal level) or battery operated circuits of electronic equipment.
Overvoltage Category II (as defined in IEC 61010-1)
A measure of the contaminates that could occur in the environment around and within a product.
Typically the internal environment inside a product is considered to be the same as the external.
Products should be used only in the environment for which they are rated.
Pollution Degree 1 No pollution or only dry, nonconductive pollution occurs. Products in this
category are generally encapsulated, hermetically sealed, or located in
clean rooms.
Pollution Degree 2 Normally only dry, nonconductive pollution occurs. Occasionally a
temporary conductivity that is caused by condensation must be expected.
This location is a typical office/home environment. Temporary
condensation occurs only when the product is out of service.
Pollution Degree 2 Conductive pollution, or dry, nonconductive pollution that becomes
conductive due to condensation. These are sheltered locations where
neither temperature nor humidity is controlled. The area is protected from
direct sunshine, rain, or direct wind.
Pullution Degree 2 (as defined in IEC 61010-1). Note: Rated for indoor use only.
Equipment type:
Test and Measuring
Installation Category II (as defined in IEC 61010-1, Annex J)
Pollution Degree 2 (as defined in IEC 61010-1)
Safety Class 1 - - grounded product
Standard for Electrical Measuring and Test Equipment.
Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use.
Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use.
