Table 1-2: Mainframe (Cont.)
Characteristics
Serial interface (Com)
Connector type
Pin assignments
IEEE1394B interface
Compliant
Pin assignments
AC line power
Rating Voltage
Voltage Range
Frequency Range
Maximum power
Maximum current
Main fuse data
RTX100A ISDB-T RF Signal Generator Service Manual
Description
RS-232C
D-sub, 9 pin
1 DCD
2 RX
3 TX
4 DTR
5 GND
IEEE1394B- - 2002
1 TPB- -
2 TPB+
3 TPA- -
4 TPA+
5 TPA (R)
100 VAC to 240 VAC, CAT II
90 VAC to 250 VAC
50 Hz to 60 Hz
180 VA
1.3 A
5 A Time- - delayed, 250 V (not operator replaceable)
2 A Time- - delayed, 250 V (not operator replaceable)
6 DSR
7 RTS
8 CTS
9 RI
6 VG
7 NC
8 VP
9 TPB (R)
