8. Use the Peak Search function of the spectrum analyzer to verify that the
carrier appears at 473.143 MHz on the screen.
9. Turn off the Carrier output of the spectrum analyzer.
10. Adjust the DAC(I) Offset and DAC(Q) Offset values so that the carrier
leakage on the spectrum analyzer is less than - -80 dBm.
11. Change Reference Frequency (output channel) on the RTX100A and center
frequency on the spectrum analyzer as listed in Table 4-2, and repeat steps 5
through 10.
NOTE. The center frequency settings for the spectrum analyzer are indicated by
boldface in the Table 4-2.

Table 4-2: Output channel and center frequency settings

Center Frequency
(MHz)
CH
13 473.143
14 479.143
15 485.143
16 491.143
17
497.143
18 503.143
19 509.143
20 515.143
21 521.143
22 527.143
23
533.143
24 539.143
25 545.143
26 551.143
27 557.143
28 563.143
29 569.143
Center frequency
(MHz)
CH
30 575.143
31 581.143
32 587.143
33 593.143
34 599.143
35 605.143
36 611.143
37 617.143
38
623.143
39 629.143
40 635.143
41 641.143
42 647.143
43 653.143
44 659.143
45 665.143
46 671.143
Adjustment Procedures
Center frequency
(MHz)
CH
47 677.143
48 683.143
49 689.143
50 695.143
51 701.143
52 707.143
53
713.143
54 719.143
55 725.143
56 731.143
57 737.143
58 743.143
59 749.143
60 755.143
61 761.143
62 767.143
- - - - - - - - - - - - - - - - - - - - - - - - - - - -
