Removal and Installation Procedures
Figure 5-12: Hard disk drive removal
5-28
d. Grasp the hard disk drive and pull it gently away from the chassis.
4. Reinstallation: Perform step 3 in reverse order to reinstall the hard disk
drive.
Hard disk drive unit
Plate
Hard disk drive retainer
RTX100A ISDB-T RF Signal Generator Service Manual
