Figure 3-4: Equipment Connections For Checking The External Clock/Reference And Trigger Inputs - Tektronix RTX100A Service Manual

Function generator (AFG3102)
50 Ω BNC cable
RTX100A rear panel

Figure 3-4: Equipment connections for checking the external clock/reference and trigger inputs

RTX100A ISDB-T RF Signal Generator Service Manual
MPEG analyzer (MTS430)
50 Ω BNC cable
Parallel interface cable
4. Set the function generator settings as indicated below:
Ch 1 output
Function . . . . . . . . . . .
Run Mode . . . . . . . . . .
Frequency . . . . . . . . . .
Output Amplitude
Output Offset . . . . . . .
Ch 2 output
Function . . . . . . . . . . .
Run Mode . . . . . . . . . .
Output Menu . . . . . . . .
Output Amplitude
Output Offset . . . . . . .
5. Press the On button of the Ch1 output on the function generator.
6. Open the test64.TRP file on the RTX100A.
a. Select File > Open in the Play screen to open the Select File dialog box.
b. In the dialog box, select the test64.TRP file.
Square
Continuous
10 MHz
. . . . 0.5 V
2.0 V
Arb (Edit: Point Number: 100,
All Data: 16382)
Continuous
Load Impedance: 1 kΩ
. . . . 1.75 V
0.875 V
Performance Verification
3-9
