Hardware Address field

Email Settings page

Select System
Configuration.
Refresh.

Mail IP Address field

User Name field

www.camboard.de
CAMBOARD Electronics
The Hardware Address field is hardcoded on the primary controller board in BME
0 and cannot be changed.
The Email Settings page (figure 5-7) can be reached by clicking on the Email
Settings link on the system configuration page. The e-mail settings page has fields
for entering all of the information needed to set up the switcher's e-mail
notification capabilities. After editing any of the settings on this page, click the
Submit button.
Figure 5-7 — Email Settings page
The Mail IP Address field displays the IP address of the mail server that handles
the e-mail for the facility in which the Matrix 12800 is installed.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric subfields separated by
dots (periods). Each field can be numbered from 000 through 255. Leading zeroes,
up to 3 digits total per field, are optional. Values of 256 and above are invalid.
The mail server User Name field displays the domain name of the Matrix 12800
e-mail server (such as folklore.net in the examples throughout this chapter).
Standard domain conventions (xxx.com) apply.
The following characters are invalid in a domain name: {space} ~ = ' [ ] { }
< > ' " ; : | \ and ?. The @ character is only acceptable as the lead-in to
the domain name (such as @folklore.net).
Tel. 07131 911201
Fax 07131 911203
ce-info@camboard.de
Matrix 12800 Switchers • Web Operation 5-7
