Web Operation, cont'd
Muting and unmuting one or all outputs
Mute one or all outputs as follows:
1.
Figure 5-13 — Output selection drop box
2.
3.
4.
5.
Changing the RGB delay
The RGB delay interval defines how long the screen is blanked when switching to a
new input for the selected output.
Change the RGB delay as follows:
1.
Figure 5-14 — Output selection drop box
2.
3.
www.camboard.de
5-12
Matrix 12800 Switchers • Web Operation
CAMBOARD Electronics
To select an individual output to mute or unmute, click the Output drop box.
A drop-down scroll box appears (figure 5-13).
Click and drag the slider or click the scroll up ( ) button or scroll down ( )
button until the desired output is visible.
Click the desired output.
Click the Video Only, Audio Only, or Video & Audio button to select video,
audio, or both for muting. Each mouse click on a button toggles the other two
buttons off.
Click the Mute or UnMute button to mute or unmute the selected output.
Click the Mute All or UnMute All to mute or unmute all of the outputs.
The Mute status indications are displayed in the lower right
corner of the page.
Click on the Output drop box. A drop-down scroll box appears (figure 5-14).
Click and drag on the slider or click on the scroll up ( ) button or scroll down
( ) button until the desired output is visible.
Click on the desired output.
