Extron electronics SYSTEM 8 Plus Installation Instructions Manual

Barco Installation
PROJECTOR COMMUNICATIONS KIT
PLEASE READ THIS DOCUMENT FOR IMPORTANT
THIS KIT HAS BEEN SHIPPED WITH THE FOLLOWING COMPONENTS:
Kit Type: BARCO
Included Communications Adapter(s):
Quantity
1
THE TABLE BELOW LISTS THE POSSIBLE CONFIGURATION(S) AND CORRESPONDING
COMMUNICATIONS ADAPTER(S) FOR YOUR PROJECTOR MANUFACTURER'S VARIOUS
MODELS. PLEASE NOTE THAT YOUR SWITCHER HAS BEEN CONFIGURED AS INDI-
CATED BY THE " " IN THE "Config as" COLUMN. IF YOUR PROJECTOR MODEL DIF-
FERS FROM THIS CONFIGURATION, YOU MUST RECONFIGURE YOUR SWITCHER
WITH THE CORRECT SETTINGS.
PLEASE REFER TO THE FOLLOWING PAGES FOR COMPLETE CONFIGURATION AND
SIGNAL CONNECTION INSTRUCTIONS.
THIS SWITCHER HAS BEEN CONFIGURED FOR:
Config Model
as
Barco LCD 5-Wire A
Barco LCD
Barco 5000
Barco CRT
Barco 6300/6400
(cable saver mode)
Extron • System 8/10 P
LUS
SYSTEM 8/10 Plus
ATTENTION!
INSTALLATION INSTRUCTIONS
Part Number
26-309-01
Rotary Switches
RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter
RC5 PPM
2 0 2
A 2 0 2
9 1 0 2
8 0 0 2
C 4 0 2
• User's Manual • P/N 68-399-01 Rev. G
Configuration and Connections
Description
Barco RCDVS Adapter
BARCO CRT
Cable SW15 Settings
↑ ↓ ↑ ↓ ↑ ↓ ↓ ↑ ↑ ↓ 26-309-01
2 J2
↑ ↓ ↑ ↓ ↑ ↓ ↓ ↓ ↑ ↓ 26-309-01
2 J2
↑ ↓ ↑ ↓ ↑ ↓ ↓ ↓ ↑ ↓ 26-309-01
2 J2
↑ ↓ ↑ ↓ ↑ ↓ ↓ ↓ ↑ ↓ 26-309-01
2 J2
↑ ↓ ↑ ↓ ↑ ↓ ↓ ↑ ↑ ↓ 26-309-01
2 J2
Comm
Page 1
