Assorted connectors

BNC connectors
BNC Mini HR crimp connectors, qty. 50
SHRmale crimp connectors, qty. 50
BNC bulkhead connectors, qty. 50

Pre-cut cables

BNC-4 Mini HR cable is used for RGBS cable runs, and BNC-5 Mini HR cable is
used for RGBHV cable runs. Either type can also be used for composite video,
S-video, or RGsB. All Extron BNC cables have male connectors on both ends. A
plenum version of the BNC-5 Mini HR cable is also available.
BNC-4 mini HR cable
BNC-4-25' MHR (25 feet/7.5 meters)
BNC-4-50' MHR (50 feet/15.0 meters)
BNC-4-75' MHR (75 feet/23.0 meters)
BNC-4-100' MHR (100 feet/30.0 meters)
BNC-4-150' MHR (150 feet/45.0 meters)
BNC-4-200' MHR (200 feet/60.0 meters)
BNC-4-250' MHR (250 feet/75.0 meters)
BNC-4-300' MHR (300 feet/90.0 meters)
BNC-5 mini HR cable
BNC-5-25' MHR (25 feet/7.5 meters)
BNC-5-50' MHR (50 feet/15.0 meters)
BNC-5-75' MHR (75 feet/23.0 meters)
BNC-5-100' MHR (100 feet/30.0 meters)
BNC-5-150' MHR (150 feet/45.0 meters)
BNC-5-200' MHR (200 feet/60.0 meters)
BNC-5-250' MHR (250 feet/75.0 meters)
BNC-5-300' MHR (300 feet/90.0 meters)
www.camboard.de
B-6
Matrix 12800 Switchers • Reference Information
CAMBOARD Electronics
(for custom wall plates)
Bulk cable in lengths up to 5000' (1524 meter) rolls is available with or
without connectors.
Tel. 07131 911201
Fax 07131 911203
Part #
100-074-51
100-075-51
100-076-51
Part #
26-210-04
26-210-05
26-210-06
26-210-07
26-210-08
26-210-09
26-210-54
26-210-53
Part #
26-260-03
26-260-04
26-260-16
26-260-05
26-260-12
26-260-06
26-260-18
26-260-14
