Virtualization/Control Software, cont'd
Remote controlling the Matrix 12800 system
BME 0 saves the settings in non-volatile memory, so once the system is virtualized,
there is no requirement to ever run the Virtualization/Control program again.
However, the Matrix 12800 can be remotely operated from a PC, running the
Virtualization/Control software, connected to either of the RS-232/RS-422 ports or
the Ethernet port on BME 0. Use the Virtualization/Control software to control the
matrix as follows:
1.
2.
3.
4.
www.camboard.de
3-14
Matrix 12800 Switchers • Virtualization/Control Software
CAMBOARD Electronics
Ensure that all BMEs that are part of the system have been connected to each
other and their BME numbers have been set correctly. Ensure that the system
has been virtualized before creating any rooms (see Creating a virtual I/O
switching system (map) in this chapter).
On the PC, click Start>Programs>Extron Electronics>Matrix 12800 Control
Program to start the program. You will be asked to select the appropriate PC
Comm port or the Ethernet port or to select Emulate mode (figure 3-1).
After you select the Comm port or the Ethernet port and click OK, the
software looks for the Matrix system and reads its hardware configuration,
the type and size of each BME. The software then reads all of the current
settings, such as the ties, presets, and virtual map, and displays a graphical
representation of the ties in the program window (figure 3-2). The program
also reads the appropriate .ini file (saved from the last session) to draw any
icons assigned to each I/O.
If this is a new system that has not been virtualized yet or one that has had its
map cleared, the graphical representation and all information shown on the
Virtual Map screen will be invalid at this point.
If you clicked Emulate to create a program for a system in advance without
being connected to it, you will have to define the number and type (video, sync,
or audio) of BMEs, the number of inputs, and the number of outputs for the
Matrix 12800 system you are emulating. See Programming the matrix
offline (emulate mode) in this chapter.
The main screen shows the current switcher configuration.
As desired, create ties, work with presets, or assign icons. See Ties, Presets, or
Icons and captions on the following pages.
When you are ready to exit the program, click File>Exit.
If you have edited any of the configurations or assigned names or icons to the
virtual inputs and outputs, the program prompts you to save changes before
closing. Changes are written to the file Mtrx12800.ini, unless you specify a
different file. This file allows you to completely restore all of the information
that you have created in the current session.
