Installing the power supply module
www.camboard.de
CAMBOARD Electronics
4.
If a replacement power supply is not being installed immediately, close the
fan assembly door and turn the left and right knurled knobs ¼-turn clockwise.
Ensure that you close and secure the fan assembly door when you have
CAUTION
finished this maintenance procedure. The Matrix 12800 may overheat
otherwise.
5.
If a replacement power supply is not being installed immediately, close the
front door.
The power supply modules are hot-swappable. You do not need to power down
the switcher to install a power supply.
Install a power supply module as follows:
1.
If necessary, open the front door.
2.
If necessary, turn the left and right knurled knobs on the fan assembly door ¼-
turn counterclockwise. Raise the door and rest it on the roof of the power
distribution enclosure.
3.
Orient the power supply module to be installed with the LEDs to the right
and near the bottom (figure 6-5).
4.
Identify the correct position to install the power supply module. Align the
flanges on the power supply module with the top and bottom power supply
guides. Gently slide the power supply module into the power distribution
enclosure until the module meets resistance.
5.
Push down on the thumb detent, and firmly push the power supply module
the rest of the way into the power distribution enclosure until the power
supply module is properly seated on the power distribution plane. If the
switcher is powered up, observe that the two LEDs light. Release the thumb
detent.
Ensure that you close the fan assembly door when you have finished this
CAUTION
maintenance procedure. The Matrix 12800 may overheat otherwise.
6.
Lower the fan assembly door to vertical and turn the left and right knurled
knobs ¼-turn clockwise.
7.
Close the front door.
If you are upgrading the matrix switcher from a configuration with two power
supplies to a configuration with four power supplies (adding redundancy), you
will need to plug in the redundant IEC power cord on the rear panel.
8.
If power supplies were installed to add redundancy to the switcher, plug a
standard IEC power cord between the rear panel Redundant AC Power Input
connector and either an uninterruptible 100 to 240VAC, 50 Hz or 60 Hz power
source or a power source that is completely independent from the primary
power source.
Tel. 07131 911201
Matrix 12800 Switchers • Upgrades and Maintenance
Fax 07131 911203
ce-info@camboard.de
6-7
